BRC-70 < DTC/CIRCUIT DIAGNOSIS > [VDC/TCS/ABS] C1164, C1165, C1166, C1167 CV/SV SYSTEM *: On for 1 to 2 seconds after the touch, and then Off Is the inspection result normal? YES >> Inspection End NO >> Go to diagnosis procedure. Refer to Special Repair Requirement INFOID:0000000006649001 1. ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION Always perform neutral position adjustment for the steering angle sensor when replacing the ABS actuator and electric unit (control unit). Refer to BRC-8, "ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL . >> GO TO 2 2. CALIBRATION OF DECEL G SENSOR Always perform calibration of decel G sensor when replacing the ABS actuator and electric unit (control unit). BRC-9, "CALIBRATION OF DECEL G SENSOR : Description" >> END RR LH ABS SOLENOID (ACT) RR LH IN SOL Off Off Off RR LH OUT SOL Off Off Off CV2 Off On On SV2 Off On* Off Operation ABS solenoid valve (ACT) Up ACT UP ACT KEEP |
