Nissan Titan A60. Manual - part 126





AV

CENTER SPEAKER

AV-329

< REMOVAL AND INSTALLATION >

[PREMIUM WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

CENTER SPEAKER

Removal and Installation

INFOID:0000000006166639

CENTER SPEAKER

Removal

1. Remove the center console. Refer to

IP-19, "Removal and Installation"

.

2. Remove the cluster lid D. Refer to

IP-15, "Removal and Installation"

.

3. Remove the center speaker screws and remove the center

speaker.

Installation

Installation is in the reverse order of removal.

WKIA1495E

AV-330

< REMOVAL AND INSTALLATION >

[PREMIUM WITH NAVIGATION]

FRONT DOOR SPEAKER

FRONT DOOR SPEAKER

Removal and Installation

INFOID:0000000006166640

FRONT DOOR SPEAKER

Removal

1. Remove the front door finisher. Refer to

INT-10, "Removal and Installation"

.

2. Remove the four front door speaker screws.
3. Disconnect the front door speaker connector and remove the

front door speaker.

Installation

Installation is in the reverse order of removal.

WKIA1498E

AV

REAR DOOR SPEAKER

AV-331

< REMOVAL AND INSTALLATION >

[PREMIUM WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

REAR DOOR SPEAKER

Removal and Installation

INFOID:0000000006166641

REAR DOOR SPEAKER

Removal

1. Remove the rear door finisher. Refer to

INT-10, "Removal and Installation"

 (Crew Cab) or

INT-10,

"Removal and Installation"

 (King Cab).

2. Remove the three rear door speaker screws and remove the

rear door speaker.

Installation

Installation is in the reverse order of removal.

REAR DOOR TWEETER

Removal

1. Remove the rear door finisher. Refer to

INT-10, "Removal and Installation"

.

2. Remove the rear door tweeter screws and remove the rear door

tweeter.

3. Disconnect the rear door tweeter connector.

Installation

Installation is in the reverse order of removal.

WKIA1492E

WKIA1494E

AV-332

< REMOVAL AND INSTALLATION >

[PREMIUM WITH NAVIGATION]

SUBWOOFER

SUBWOOFER

Removal and Installation

INFOID:0000000006166642

SUBWOOFER

Removal

1. Remove the front seat LH. Refer to

SE-30, "Removal and Installation For Front Seat"

.

2. Disconnect the subwoofer connector (B).

: Vehicle front

3. Remove the subwoofer bolts (A).
4. Remove the subwoofer (1).

Installation

Installation is in the reverse order of removal.

ALNIA1127ZZ
