Nissan Quest E52. Manual - part 330
DLK-34
< SYSTEM DESCRIPTION >
SYSTEM (POWER DOOR LOCK SYSTEM)
BCM outputs the lock signal to all door lock actuators when it detects that the ignition switch is turned ON, all
doors are closed and the vehicle speed received from the combination meter via CAN communication
becomes 24 km/h (15 MPH) or more.
P Range Interlock Door Lock
All doors are locked when shifting the selector lever from the P position to any position other than P.
BCM outputs the lock signal to all door lock actuators when it detects that the ignition switch is in the ON posi-
tion, all doors are closed and the shift signal received from the TCM via CAN communication shifted from the
P position to any position other than P.
Setting change of Automatic Door Lock/Unlock Function
The lock operation setting of the automatic door lock/unlock function can be changed.
With CONSULT
The ON/OFF switching of the automatic door lock function and the type selection of the automatic door lock/
unlock function can be performed at the WORK SUPPORT setting of CONSULT.
Without CONSULT
The automatic door lock function ON/OFF can be switched by performing the following operation.
1.
Close all doors (door switch OFF)
2.
Ignition switch: OFF
→
ON
3.
Press and hold the door lock and unlock switch for 5 seconds or more in the lock direction within 20 sec-
onds after turning the ignition switch ON.
4.
The switching complete when the hazard lamp blinks.
AUTOMATIC DOOR LOCK/UNLOCK FUNCTION (UNLOCK OPERATION)
The automatic door lock/unlock function is the function that unlocks all doors linked with the key position or
shift position. It has 2 types as per the following items.
IGN OFF Interlock Door Unlock
All doors are unlocked when the power supply position is changed from ON to OFF.
BCM outputs the unlock signal to all door lock actuators when it detects that the power supply position is
changed from ignition switch ON to OFF.
P Range Interlock Door Unlock
All doors are unlocked when shifting the selector lever from any position other than the P to P position.
BCM outputs the unlock signal to all door lock actuators when it detects that the ignition switch is in the ON
position and the shift signal received from TCM via CAN communication is shifted from any position other than
the P to P position.
Setting change of Automatic Door Lock/Unlock Function
The unlock operation setting of the automatic door lock/unlock function can be changed.
With CONSULT
The ON/OFF switching of the automatic door lock/unlock function and the type selection of the automatic door
lock/unlock function can be performed at the WORK SUPPORT setting of CONSULT.
Without CONSULT
The automatic door lock/unlock function ON/OFF can be switched by performing the following operation.
1.
Close all doors (door switch OFF)
2.
Ignition switch: OFF
→
ON
3.
Press and hold the door lock and unlock switch for 5 seconds or more in the unlock direction within 20
seconds after turning the power supply position ON.
4.
The switching is complete when the hazard lamp blinks.
OFF
→
ON
: 2 blinks
ON
→
OFF
: 1 blink
OFF
→
ON
: 2 blinks
ON
→
OFF
: 1 blink
