TM-150 < PERIODIC MAINTENANCE > [CVT: RE0F09B] CVT FLUID Check CVT fluid condition. Flush cooling system after repair of CVT. • If CVT fluid contains frictional material (clutches, brakes, etc.), replace radiator and flush cooler line using cleaning solvent and Changing INFOID:0000000009650220 CAUTION: Replace a O-ring with new ones at the final stage of the operation when installing. 1. Remove drain plug from oil pan. 2. Remove O-ring from drain plug. 3. Install O-ring to drain plug. CAUTION: Never reuse O-ring. 4. Install drain plug to oil pan. Refer to . 5. Fill CVT fluid from CVT fluid charging pipe to the specified level. CAUTION: • Use only recommended CVT fluid. Never mix with other fluid. CVT durability, and may damage the CVT, which is not covered by the warranty. • When filling CVT fluid, take care not to scatter heat generating parts such as exhaust. 6. With the engine warmed up, drive the vehicle in an urban area. ° C (68 ° F), it takes about 10 minutes for the CVT fluid to warm up to 50 to 80 ° C (122 to 176 ° F). 7. Check CVT fluid level and condition. 8. Repeat steps 1 to 5 if CVT fluid has been contaminated. Fluid status Conceivable cause Required operation Varnished (viscous CVT fluid becomes Replace the CVT fluid and check the Milky white or Water in the fluid Replace the CVT fluid and check for Large amount of Unusual wear of Replace the CVT fluid and check for ATA0022D Recommended fluid and fluid capacity : Refer to |
