Nissan Quest E52. Manual - part 1014
REAR WHEEL HUB AND HOUSING
RAX-7
< REMOVAL AND INSTALLATION >
C
E
F
G
H
I
J
K
L
M
A
B
RAX
N
O
P
14. Remove axle housing.
15. Remove hub cap.
16. Remove hub bolts (1) from wheel hub assembly, using the ball
joint remover (A) (commercial service tool).
CAUTION:
• Remove hub bolt only when necessary.
• Never hammer the hub bolt to avoid impact to the wheel
hub assembly.
• Pull out the hub bolt in a direction perpendicular to the
wheel hub assembly.
17. Perform inspection after removal. Refer to
.
INSTALLATION
Note the following, and install in the reverse order of removal.
• Place a washer (A) as shown in the figure to install the hub bolts
(1) by using the tightening force of the nut (B).
CAUTION:
• Check that there is no clearance between wheel hub assem-
bly and hub bolt.
• Never reuse hub bolt.
• Align the matching marks that have been made during removal
when reusing the disc rotor.
• Perform the final tightening of each of parts under unladen condi-
tions, which were removed when removing suspension compo-
nent.
• Never reuse cotter pin and bushing.
• Perform inspection after installation. Refer to
.
Inspection
INFOID:0000000009650477
INSPECTION AFTER REMOVAL
Check the wheel hub assembly for wear, cracks, and damage. Replace if necessary.
INSPECTION AFTER INSTALLATION
1.
Check wheel sensor harness for proper connection.
BRC-120, "REAR WHEEL SENSOR : Exploded
.
2.
Adjust parking brake operation (stroke). Refer to
PB-3, "Inspection and Adjustment"
3.
Check wheel alignment. Refer to
4.
Adjust neutral position of steering angle sensor. Refer to
.
JPDIF0299ZZ
JPDIF0300ZZ
