MEMORY INDICATE DOES NOT OPERATE

ADP-109

< SYMPTOM DIAGNOSIS >

C

D

E

F

G

H

I

K

L

M

A

B

ADP

N

O

P

MEMORY INDICATE DOES NOT OPERATE

Diagnosis Procedure

INFOID:0000000009649706

1.

CHECK SEAT MEMORY SWITCH INDICATOR

Check seat memory switch indicator.
Refer to

ADP-98, "Component Function Check"

.

Is the inspection result normal?

YES

>> GO TO 2.

NO

>> Repair or replace the malfunction parts.

2.

CONFIRM THE OPERATION

Confirm the operation again.

Is the result normal?

YES

>> Check intermittent incident. Refer to

GI-42, "Intermittent Incident"

.

NO

>> GO TO 1.

ADP-110

< SYMPTOM DIAGNOSIS >

NORMAL OPERATING CONDITION

NORMAL OPERATING CONDITION

Description

INFOID:0000000009649707

The following symptoms are normal operations, and they do not indicate a malfunction.

Symptom

Cause

Action to take

Reference page

Entry/exit assist function do not
operate.

No initialization has been performed.

Perform initialization.

ADP-48, "Description"

Entry/exit assist function is disabled.
NOTE:
Entry/exit assist function is set to ON be-
fore delivery (initial setting).

Change the settings.

ADP-51, "Description"

Entry assist function does not op-
erate.

Manual operation with power seat switch
was performed after exit assist function
execution.

Perform the entry as-

sist function.

ADP-18, "ENTRY AS-

SIST FUNCTION : Sys-

tem Description"

Lumbar support does not per-
form memory operation.

The lumbar support system are con-
trolled independently with no link to the
automatic drive positioner system.

—

SE-13, "POWER SEAT

SYSTEM : System De-

scription"

Memory function, entry/exit as-
sist function, or Intelligent Key in-
terlock function does not
operate.

The operating conditions are not fulfilled.

Fulfill the operation

conditions.

Memory function :

ADP-15, "MEMORY

FUNCTION : System

Description"

Entry assist function :

ADP-18, "ENTRY AS-

SIST FUNCTION : Sys-

tem Description"

Exit assist function :

ADP-17, "EXIT ASSIST

FUNCTION : System

Description"

Intelligent Key interlock

function :

ADP-19, "IN-

TELLIGENT KEY IN-

TERLOCK FUNCTION :

System Description"

DRIVER SEAT CONTROL UNIT

ADP-111

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

K

L

M

A

B

ADP

N

O

P

REMOVAL AND INSTALLATION

DRIVER SEAT CONTROL UNIT

Removal and Installation

INFOID:0000000009649708

REMOVAL

1.

Remove driver seat. Refer to

SE-102, "Removal and Installa-

tion"

.

2.

Remove screws (A), and then remove driver seat control unit (2)
from seat cushion frame (1)

INSTALLATION

Install in the reverse order of removal.
NOTE:
After installing the driver seat, perform additional service when replacing control unit. Refer to

ADP-47,

"Description"

.

JMJIA4721ZZ

ADP-112

< REMOVAL AND INSTALLATION >

AUTOMATIC DRIVE POSITIONER CONTROL UNIT

AUTOMATIC DRIVE POSITIONER CONTROL UNIT

Removal and Installation

INFOID:0000000009649709

REMOVAL

1.

Remove instrument lower panel RH. Refer to

IP-14, "Removal

and Installation"

.

2.

Remove screw (A), and then remove automatic drive positioner
control unit (2) from bracket (1).

INSTALLATION

Install in the reverse order of removal.
NOTE:
After installing the driver seat, perform additional service when replacing control unit. Refer to

ADP-47,

"Description"

.

JMJIA6178ZZ
