EXIT ASSIST FUNCTION : System Description
INFOID:0000000009649603
SYSTEM DIAGRAM
DESCRIPTION
• This function slides driver seat toward vehicle rear and facilitates entry/exit of the vehicle.
• Seat slide set amount of exit assist function is adjustable.
• When driver side door is open while operation conditions are satisfied, driver seat control unit receives front
door switch (driver side) signal (open/close) from BCM via CAN communication. Driver seat control unit
operates sliding motor and moves driver seat toward vehicle rear to the seat slide set amount when driver
seat control unit detects that driver side door is open.
• Driver seat control unit receives sliding sensor position signal from sliding sensor. Driver seat control unit
stops the operation of sliding motor when driver seat control unit detects that driver seat is slid to the seat
slide set amount.
NOTE:
• This function is set to ON before delivery (initial setting).
• Further information for the system setting procedure. Refer to
Operation Condition
Satisfy all of the following items. The exit assist function is not performed if these items are not satisfied.
JMJIA5857GB
Item
Request status
Ignition position
OFF
System setting (Entry/exit assist function)
ON
Initialization
Done
Switch inputs
• Power seat switch
• Door mirror remote control switch
• Set switch
• Memory switch
OFF
(Not operated)
CVT shift selector
P position
Handle position
LHD
