OVERDRIVE CONTROL SWITCH

Component Inspection (Overdrive Control Switch)

INFOID:0000000009949044

1.

CHECK OVERDRIVE CONTROL SWITCH

Check continuity between CVT shift selector vehicle connector terminals.

With intelligent key system

Without intelligent key system

Is the inspection result normal?

YES

>> INSPECTION END

NO

>> Repair or replace damaged parts.

CVT shift selector connector

Condition

Continuity

Connector

Terminal

M58

1

2

Press and hold overdrive control switch

Existed

Other conditions

Not existed

CVT shift selector connector

Condition

Continuity

Connector

Terminal

M57

1

2

Press and hold overdrive control switch

Existed

Other conditions

Not existed

SHIFT POSITION INDICATOR CIRCUIT

TM-165

< DTC/CIRCUIT DIAGNOSIS >

[CVT: RE0F08B]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

SHIFT POSITION INDICATOR CIRCUIT

Description

INFOID:0000000009949045

TCM transmits shift position signal to combination meter via CAN communication. The actual shift position is
displayed on combination meter according to the signal.

Component Function Check

INFOID:0000000009949046

1.

CHECK SHIFT POSITION INDICATOR

1.

Start the engine.

2.

Shift selector lever.

3.

Check that the selector lever position and shift position indicator on combination meter are equivalent.

Is the inspection result normal?

YES

>> INSPECTION END

NO

>> Go to

TM-165, "Diagnosis Procedure"

.

Diagnosis Procedure

INFOID:0000000009949047

1.

CHECK TCM INPUT AND OUTPUT SIGNALS

With CONSULT

1.

Start the engine.

2.

Select “Data Monitor” in “TRANSMISSION”.

3.

Select “RANGE”.

4.

Shift selector lever.

5.

Check that selector lever position, “RANGE” on CONSULT screen, and shift position indicator display on
combination meter are identical.

 Is the inspection result normal?

YES

>> INSPECTION END

NO-1 (“RANGE” is changed but is not displayed on shift position indicator.)>>Select

“Self

Diagnostic

Results” in “TRANSMISSION”.

NO-2 (“RANGE” differs from shift position indicator.)>>Select “Self Diagnostic Results” in “TRANSMISSION”.
NO-3 (Specific“RANGE” is not displayed on shift position

indicator.)>>Select “Self Diagnostic Results” in

“METER/M&A”.

TM-166

< DTC/CIRCUIT DIAGNOSIS >

[CVT: RE0F08B]

SHIFT LOCK SYSTEM

SHIFT LOCK SYSTEM

Description

INFOID:0000000009949048

Component

Function

Shift lock solenoid

It operates according to the signal from the stop lamp switch and moves the lock
lever.

Lock lever

• It is rotated according to shift lock solenoid activation and shift lock is released.
• If shift lock solenoid does not activate, lock lever can be rotated when shift lock

release button is pressed and shift lock is released.

Detent plate

It links with the selector button and restricts the selector lever movement.

Park position switch

It detects that the selector lever is in “P” position.

Shift lock release button

It moves the lock lever forcibly.

SHIFT LOCK SYSTEM

TM-167

< DTC/CIRCUIT DIAGNOSIS >

[CVT: RE0F08B]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

Wiring Diagram - SHIFT LOCK SYSTEM -

INFOID:0000000009949049

JCDWM0583GB
