RSU-1

SUSPENSION

C

D

F

G

H

I

J

K

L

M

SECTION

RSU

A

B

RSU

N

O

P

CONTENTS

REAR SUSPENSION

SYMPTOM DIAGNOSIS  ...............................

2

NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING  .............................

2

NVH Troubleshooting Chart  ......................................

2

PRECAUTION ...............................................

3

PRECAUTIONS ...................................................

3

Precautions for Suspension  ......................................

3

Precautions for Removing of Battery Terminal  .........

3

PREPARATION ............................................

4

PREPARATION ...................................................

4

Commercial Service Tool  ..........................................

4

PERIODIC MAINTENANCE ..........................

5

REAR SUSPENSION ASSEMBLY  .....................

5

Inspection ..................................................................

5

WHEEL ALIGNMENT ..........................................

6

Inspection ..................................................................

6

REMOVAL AND INSTALLATION  ................

7

REAR SHOCK ABSORBER  ..............................

7

Exploded View ..........................................................

7

Removal and Installation  ..........................................

7

Inspection .................................................................

8

Disposal ....................................................................

8

COIL SPRING  ....................................................

9

Exploded View ..........................................................

9

Removal and Installation  ..........................................

9

Inspection .................................................................

9

REAR SUSPENSION BEAM ............................

11

Exploded View .........................................................

11

Removal and Installation  .........................................

11

Inspection ................................................................

12

SERVICE DATA AND SPECIFICATIONS
(SDS) ............................................................

13

SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................

13

Wheel Alignment  .....................................................

13

Wheelarch Height  ....................................................

13

RSU-2

< SYMPTOM DIAGNOSIS >

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

SYMPTOM DIAGNOSIS

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NVH Troubleshooting Chart

INFOID:0000000009948838

Use chart below to find the cause of the symptom. If necessary, repair or replace these parts.

×

: Applicable

Reference

RSU-7

,

RSU-9

,

RSU-1

1

RSU-7

—

—

—

RSU-7

,

RSU-9

,

RSU-1

1

RSU-6

NVH

in

RAX and RSU sections

NVH in WT section

NVH in WT section

NVH in BR section

Possible cause and SUSPECTED PARTS

Imp

rop

er i

ns

ta

lla

ti

o

n,

 lo

os

en

es

s

Sh

oc

k

ab

so

rbe

r de

form

a

tio

n,

dam

a

g

e

 or d

e

flec

ti

on

Bu

sh

in

g o

r m

o

u

n

ti

ng

 de

teri

ora

tio

n

Part

s interf

erence

S

p

rin

g

 f

a

ti

gu

e

Su

sp

en

si

on

 lo

os

en

es

s

In

co

rrec

t wh

ee

l a

lig

nm

en

t

REAR A

X

LE

AND REAR SUSPE

NSION

TI

RE

ROAD WHEE

L

BRAKE

Symptom

REAR SUSPENSION

Noise

×

×

×

×

×

×

×

×

×

×

Shake

×

×

×

×

×

×

×

×

×

Vibration

×

×

×

×

×

×

×

Shimmy

×

×

×

×

×

×

×

×

×

Judder

×

×

×

×

×

×

×

Poor quality ride or handling

×

×

×

×

×

×

×

×

×

PRECAUTIONS

RSU-3

< PRECAUTION >

C

D

F

G

H

I

J

K

L

M

A

B

RSU

N

O

P

PRECAUTION

PRECAUTIONS

Precautions for Suspension

INFOID:0000000009948839

• When installing rubber bushings, the final tightening must be carried out under unladen conditions with tires

on ground. Spilled oil might shorten the life of rubber bushings. Be sure to wipe off any spilled oil.

- Unladen conditions mean that fuel, engine coolant and lubricant are full. Spare tire, jack, hand tools and

mats are in designated positions.

• After servicing suspension parts, be sure to check wheel alignment.
• Self-lock nuts are not reusable. Always use new ones when installing. Since new self-lock nuts are pre-oiled,

tighten as they are.

Precautions for Removing of Battery Terminal

INFOID:0000000010085533

•  When removing the 12V battery terminal, turn OFF the ignition

switch and wait at least 30 seconds.
NOTE:
ECU may be active for several tens of seconds after the ignition
switch is turned OFF. If the battery terminal is removed before ECU
stops, then a DTC detection error or ECU data corruption may
occur.

•  For vehicles with the 2-batteries, be sure to connect the main bat-

tery and the sub battery before turning ON the ignition switch.
NOTE:
If the ignition switch is turned ON with any one of the terminals of
main battery and sub battery disconnected, then DTC may be
detected.

•  After installing the 12V battery, always check "Self Diagnosis Result" of all ECUs and erase DTC.

NOTE:
The removal of 12V battery may cause a DTC detection error.

SEF289H

RSU-4

< PREPARATION >

PREPARATION

PREPARATION

PREPARATION

Commercial Service Tool

INFOID:0000000009948840

Tool name

Description

Power tool

Loosening bolts and nuts

PBIC0190E
