POWER SUPPLY AND GROUND CIRCUIT WT-35 < DTC/CIRCUIT DIAGNOSIS > C D F G H I J K L M A B WT N O P POWER SUPPLY AND GROUND CIRCUIT Diagnosis Procedure INFOID:0000000009949873 1. POWER SUPPLY SYSTEM CHECK 1. Turn the ignition switch OFF. 2. Disconnect the BCM harness connector. 3. Turn the ignition switch ON. CAUTION: Never start the engine. 4. Check the voltage between the BCM harness connector and the ground. *1: With intelligent key system YES >> GO TO 2. NO >> Repair or replace damaged parts. 2. GROUND SYSTEM INSPECTION 1. Turn the ignition switch OFF. 2. Check the continuity between the BCM harness connector and the ground. *1: With intelligent key system Is the inspection result normal? YES >> • Check the 10A fuse [No. 11 in fuse block (J/B)]. • Check the 40A fusible link [No. G in fuse block]. NO >> Repair or replace damaged parts. BCM — Voltage Connector Terminal M70 *1 M67 *2 57 Ground Battery voltage 70 BCM — Continuity Connector Terminal M70 *1 M67 *2 67 Ground Existed |
