WARNING CHIME SYSTEM

WCS-31

< DTC/CIRCUIT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

JRNWD0656GB

WCS-32

< DTC/CIRCUIT DIAGNOSIS >

WARNING CHIME SYSTEM

JRNWD0657GB

WCS

COMBINATION METER

WCS-33

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

ECU DIAGNOSIS INFORMATION

COMBINATION METER

Reference Value

INFOID:0000000010244838

VALUES ON THE DIAGNOSIS TOOL

NOTE:
The following table includes information (items) inapplicable to this vehicle. For information (items) applicable
to this vehicle, refer to CONSULT display items.

Monitor Item

Condition

Value/Status

SPEED METER
[km/h]

Ignition switch
ON

While driving

Equivalent to speedometer reading
NOTE:
655.35 is displayed when the malfunc-
tion signal is received

SPEED OUTPUT
[km/h]

Ignition switch
ON

While driving

Equivalent to speedometer reading
NOTE:
655.35 is displayed when the malfunc-
tion signal is received

ODO OUTPUT
[km/h or mph]

Ignition switch
ON

Equivalent to odometer reading in
combination meter

TACHO METER
[rpm]

Ignition switch
ON

Engine running

Equivalent to tachometer reading
NOTE:
8191.875 is displayed when the mal-
function signal is received

FUEL METER
[L]

Ignition switch
ON

Values according to fuel level

W TEMP METER
[

°

C]

Ignition switch
ON

Values according to engine coolant
temperature
NOTE:
215 is displayed when the malfunction
signal is input

FUEL CAP W/L

Ignition switch
ON

Fuel filler cap warning display ON

On

Fuel filler cap warning display OFF

Off

ABS W/L

Ignition switch
ON

ABS warning lamp ON

On

ABS warning lamp OFF

Off

VDC/TCS IND

Ignition switch
ON

VDC OFF indicator lamp ON

On

VDC OFF indicator lamp OFF

Off

SLIP IND

Ignition switch
ON

VDC warning lamp ON

On

VDC warning lamp OFF

Off

BRAKE W/L

Ignition switch
ON

Brake warning lamp ON

On

Brake warning lamp OFF

Off

DOOR W/L

Ignition switch
ON

Door warning lamp ON

On

Door warning lamp OFF

Off

HI-BEAM IND

Ignition switch
ON

High-beam indicator lamp ON

On

High-beam indicator lamp OFF

Off

TURN IND

Ignition switch
ON

Turn signal indicator lamp ON

On

Turn signal indicator lamp OFF

Off

LIGHT IND

Ignition switch
ON

Tail lamp indicator lamp ON

On

Tail lamp indicator lamp OFF

Off

OIL W/L

Ignition switch
ON

Oil pressure warning lamp ON

On

Oil pressure warning lamp OFF

Off

WCS-34

< ECU DIAGNOSIS INFORMATION >

COMBINATION METER

MIL

Ignition switch
ON

Malfunction indicator lamp ON

On

Malfunction indicator lamp OFF

Off

CRUISE IND

Ignition switch
ON

CRUISE indicator lamp ON

On

CRUISE indicator lamp OFF

Off

SPORT IND

Ignition switch
ON

OD OFF indicator lamp ON

On

OD OFF indicator lamp OFF

Off

FUEL W/L

Ignition switch
ON

Low-fuel warning displayed

On

Low-fuel warning not displayed

Off

AIR PRES W/L

Ignition switch
ON

Low tire pressure lamp ON

On

Low tire pressure lamp OFF

Off

KEY G/Y W/L

Ignition switch
ON

KEY warning lamp (G/Y) ON

On

KEY warning lamp (G/Y) OFF

Off

KEY KNOB W/L

Ignition switch
ON

Shift P warning lamp ON

On

Shift P warning lamp OFF

Off

EPS W/L

Ignition switch
ON

EPS warning lamp ON

On

EPS warning lamp OFF

Off

e-4WD W/L

Ignition switch
ON

NOTE:
This item is displayed, but cannot be moni-
tored.

Off

LCD

Ignition switch
LOCK or ACC

Engine start operation indicator lamp ON

NIGN B&P

Ignition switch
ON

Engine start operation indicator lamp ON

IGN B&P

Ignition switch
LOCK

Shift P warning lamp ON

SFT P

Ignition switch
ON

KEY warning lamp blinking

NO KY

SHIFT IND

Ignition switch
ON

Shift position indicator P display

P

Shift position indicator R display

R

Shift position indicator N display

N

Shift position indicator D display

D

Shift position indicator L display

L

O/D OFF SW

Ignition switch
ON

Overdrive control switch ON

On

Overdrive control switch OFF

Off

PKB SW

Ignition switch
ON

Parking brake switch ON

On

Parking brake switch OFF

Off

BUCKLE SW

Ignition switch
ON

Seat belt (driver side) not fastened

On

Seat belt (driver side) fastened

Off

BRAKE OIL SW

Ignition switch
ON

Brake fluid level switch ON

On

Brake fluid level switch OFF

Off

A/C AMP CONN

Ignition switch
ON

Other than the following

On

Receives A/C auto amp. connection recog-
nition signal

Off

DISTANCE
[km]

Ignition switch
ON

Possible driving distance calculated by
combination meter

Monitor Item

Condition

Value/Status
