Nissan Cube. Manual - part 1006
WCS
SEAT BELT BUCKLE SWITCH SIGNAL CIRCUIT
WCS-27
< DTC/CIRCUIT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
L
M
B
A
O
P
3.
CHECK SEAT BELT BUCKLE SWITCH (DRIVER SIDE) GROUND CIRCUIT
Check harness continuity between seat belt buckle switch (driver side) harness connector and ground.
Is the inspection result normal?
YES
>> INSPECTION END
NO
>> Repair harness or connector.
Component Inspection
INFOID:0000000009945527
1.
CHECK SEAT BELT BUCKLE SWITCH (DRIVER SIDE)
1.
Turn ignition switch OFF.
2.
Disconnect the seat belt buckle switch (driver side) connector.
3.
Check continuity between terminals.
Is the inspection result normal?
YES
>> INSPECTION END
NO
>> Replace seat belt buckle (driver side). Refer to
SB-8, "SEAT BELT BUCKLE : Removal and Instal-
.
Terminals
Continuity
Seat belt buckle switch (driver side)
Ground
Connector
Terminal
B22
2
Exist
Terminals
Condition
Continuity
Seat belt buckle switch
(driver side)
1
2
When seat belt is fastened
Not existed
When seat belt is unfastened
Exist
