AV

AUDIO UNIT

AV-33

< ECU DIAGNOSIS INFORMATION >

[AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

9

(W)

8

(B/R)

Illumination control signal

Input

Ignition

switch

OFF

• Lighting switch 1ST
• When meter illumination

is maximum

• Lighting switch 1ST
• When meter illumination

is step 11

• Lighting switch 1ST
• When meter illumination

is minimum

0 V

11

(G)

12

(R)

Sound signal front speaker
RH

Output

Ignition

switch

ON

Sound output

13

(LG)

14

(GR)

Sound signal rear speaker
RH

Output

Ignition

switch

ON

Sound output

16

(GR/R)

15

(L/B)

Steering switch signal B

Input

Ignition

switch

ON

Keep pressing VOL DOWN
switch

0 V

Keep pressing VOL UP
switch

0.9 V

Except for above

3.3 V

18

(L)

Ground

Vehicle speed signal
(8-pulse)

Input

Ignition

switch

ON

When vehicle speed is ap-
prox. 40 km/h (25 MPH)

NOTE:
The maximum voltage varies de-
pending on the specification
(destination unit).

19

(L)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

JPNIA1687GB

JPNIA1686GB

SKIB3609E

SKIB3609E

JSNIA0012GB

AV-34

< ECU DIAGNOSIS INFORMATION >

[AUDIO WITHOUT NAVIGATION]

AUDIO UNIT

21

(R)

25

(W)

iPod sound signal LH

Input

Ignition

switch

ON

When iPod mode is select-
ed

23

(B)

27

(G)

iPod sound signal RH

Input

Ignition

switch

ON

When iPod mode is select-
ed

28

—

Shield

—

—

—

—

48

(SB)

—

AV communication signal
(H)

Input/

Output

—

—

—

49

(LG)

—

AV communication signal
(L)

Input/

Output

—

—

—

54

(O)

Ground

TEL ON signal

Input

Ignition

switch

ON

While using hands-free
phone system

0 V

While not using hands-free
phone system

5.0 V

56

(BR)

57

(Y)

Sound signal
(TEL voice, voice guid-
ance)

Input

Ignition

switch

ON

During voice guide output

with the



 switch

pressed

58

—

Shield

—

—

—

—

61

Ground

Antenna amp. ON signal

Output

Ignition

switch

ON

—

12.0  V

62

—

AM–FM main

Input

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3609E

SKIB3609E

SKIB3609E

AV

TEL ADAPTER UNIT

AV-35

< ECU DIAGNOSIS INFORMATION >

[AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

TEL ADAPTER UNIT

Reference Value

INFOID:0000000009949568

TERMINAL LAYOUT

PHYSICAL VALUES

JPNIA0011ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(R)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

2

(L)

Ground

ACC power supply

Input

Ignition

switch

ACC

—

Battery voltage

3

(LG)

Ground

Ignition signal

Input

Ignition

switch

ON

—

Battery voltage

4

(B)

Ground

Ground

—

Ignition

switch

ON

—

0  V

7

(L)

8

Microphone signal

Input

Ignition

switch

ON

Give a voice.

9

(BR)

10

(Y)

Sound signal
(TEL voice, voice guid-
ance)

Output

Ignition

switch

ON

During voice guide output

with the

 switch

pressed.

11

(SB)

Ground

TEL ON signal

Output

Ignition

switch

ON

While using hands-free
phone system.

0 V

While not using hands-free
phone system.

5.0 V

SKIB3609E

SKIB3609E

AV-36

< ECU DIAGNOSIS INFORMATION >

[AUDIO WITHOUT NAVIGATION]

TEL ADAPTER UNIT

12

(W)

14

(GR)

Steering switch signal A

Input

Ignition

switch

ON

Keep pressing SOURCE
switch.

0 V

Keep pressing SEEK UP
switch.

1.3 V

Keep pressing SEEK
DOWN switch.

2.5 V

Keep pressing



switch.

3.4 V

Except for above.

5.0 V

13

(SB)

14

(GR)

Steering switch signal B

Input

Ignition

switch

ON

Keep pressing VOL DOWN
switch.

0 V

Keep pressing VOL UP
switch.

1.3 V

Keep pressing

 switch.

2.5 V

Except for above.

5.0 V

17

(GR)

19

(L)

Steering switch signal A

Output

Ignition

switch

ON

Keep pressing SOURCE
switch.

0 V

Keep pressing SEEK UP
switch.

0.9 V

Keep pressing SEEK
DOWN switch.

1.6 V

Except for above.

3.3 V

18

(P)

19

(L)

Steering switch signal B

Output

Ignition

switch

ON

Keep pressing VOL DOWN
switch.

0 V

Keep pressing VOL UP
switch.

0.9 V

Except for above.

3.3 V

22

(B)

Ground

Control signal

—

Ignition

switch

ON

—

0  V

23

(B)

Ground

Control signal

—

Ignition

switch

ON

—

0  V

24

(B)

Ground

Control signal

—

Ignition

switch

ON

—

0  V

27

(B)

Ground

Control signal

—

Ignition

switch

ON

—

0  V

28

(O)

Ground

Vehicle speed signal
(2-pulse)

Input

Ignition

switch

ON

When vehicle speed is ap-
prox. 40 km/h (25 MPH)

NOTE:
The maximum voltage varies de-
pending on the specification
(destination unit).

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

JSNIA0015GB
