DIAGNOSIS SYSTEM (BCM)
WT-13
< SYSTEM DESCRIPTION >
C
D
F
G
H
I
J
K
L
M
A
B
WT
N
O
P
• Read TPMS DTCs
• Register TPMS transmitter IDs
• Test remote keyless entry keyfob relative signal strength
SELF DIAGNOSTIC RESULT
NOTE:
Before performing self diagnostic result, be sure to register the ID, or else the actual malfunction may be differ-
ent from that displayed on CONSULT.
.
DATA MONITOR
ACTIVE TEST
WORK SUPPORT
Monitor Item [Unit]
Description
AIR PRESS FL [kPa, kg/cm
2
or Psi]
Indicates air pressure of front LH tire.
AIR PRESS FR [kPa, kg/cm
2
or Psi]
Indicates air pressure of front RH tire.
AIR PRESS RR [kPa, kg/cm
2
or Psi]
Indicates air pressure of rear RH tire.
AIR PRESS RL [kPa, kg/cm
2
or Psi]
Indicates air pressure of rear LH tire.
ID REGST FL1 [Done/Yet]
Indicates ID registration status of front LH transmitter.
ID REGST FR1 [Done/Yet]
Indicates ID registration status of front RH transmitter.
ID REGST RR1 [Done/Yet]
Indicates ID registration status of rear RH transmitter.
ID REGST RL1 [Done/Yet]
Indicates ID registration status of rear LH transmitter.
WARNING LAMP [Off/On]
Indicates condition of low tire pressure warning lamp in combination meter.
BUZZER [Off/On]
Indicates condition of buzzer in combination meter.
Test Item
Description
HORN
This test is able to check horn operation [On].
WARNING LAMP
This test is able to check tire pressure warning lamp operation [On/Off].
ID REGIST WARNING
This test is able to check ID registration warning chime operation [On/Off].
FLASHER
This test is able to check turn signal lamp operation [Off/LH/RH].
Support Item
Description
ID READ
The registered ID number is displayed.
ID REGIST
Refer to
