GW-22

< REMOVAL AND INSTALLATION >

FRONT DOOR GLASS AND REGULATOR

7. Remove front door glass bolts (A).

8. While holding the front door glass, raise it at the rear end and

pull it out of the front door glass rear run toward the outside of

the door to remove.

9. Remove the front door glass front run bolts and remove (if necessary).
10. Remove the front door glass rear run bolts and remove (if necessary).

Installation

Installation is in the reverse order of removal.

CAUTION:

Tighten bolts to specification. Refer to

GW-21, "Exploded View"

.

Fitting Inspection

• Make sure that the glass fits securely into the front door glass run groove.

• Lower the glass slightly [approximately 10 to 20 mm (0.394 to 0.787 in)], and check that the clearance to the

sash is parallel. Loosen the regulator bolts, door sash bolts and glass bolts to correct the glass position if the

clearance between the glass and sash is not parallel.

FRONT DOOR GLASS REGULATOR

Removal

1. Disconnect the battery positive and negative terminals then wait at least three minutes. Refer to

PG-67,

"Removal and Installation (Battery)"

.

2. Remove front door finisher. Refer to

INT-15, "Removal and Installation"

.

3. Remove the vapor barrier. Refer to

GW-21, "Exploded View"

.

CAUTION:

Use care not to damage or tear vapor barrier during removal.

4. Disconnect the harness connector from the door mirror.
5. Temporarily reconnect both battery terminals and the main power window and door lock/unlock switch (LH

door) or power window and door lock/unlock switch (RH door) to raise/lower the front door glass until the

bolts can be seen through the access holes (with power window).

6. Temporarily reinstall the front door glass handle and raise/lower the front door glass until the bolts can be

seen through the access holes (without power window).

ALKIA3164ZZ

JMKIA8064ZZ

FRONT DOOR GLASS AND REGULATOR

GW-23

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

7. Remove front door glass bolts (A).

8. Raise the front door glass and hold it in place with a suitable tool or approximately two inches of mashing

tape.

9. Remove bolts and front door glass regulator.
10. Remove front power window motor from front door glass regulator (if necessary). Refer to

GW-24,

"Removal and Installation"

.

Inspection After Removal

Check the front door glass regulator for the following items:

• Wire wear

• Regulator deformation

• Grease condition for each sliding part

If a malfunction is detected, replace or grease it.

The arrows in the figure show the application points of a suitable

multi-purpose grease (if necessary).

Installation

Installation is in the reverse order of removal.

CAUTION:

Tighten front door regulator bolts to specification. Refer to

GW-21, "Exploded View"

.

Fitting Inspection

• Make sure that the glass fits securely into the sash groove.

• Lower the glass slightly [approximately 10 to 20 mm (0.394 to 0.787 in)], and check that the clearance to the

sash is parallel. Loosen the regulator bolts, door sash bolts and glass bolts to correct the glass position if the

clearance between the glass and sash is not parallel.

ALKIA3164ZZ

JMKIA4453ZZ

GW-24

< REMOVAL AND INSTALLATION >

FRONT POWER WINDOW MOTOR

FRONT POWER WINDOW MOTOR

Removal and Installation

INFOID:0000000009654177

REMOVAL

1. Remove front door glass regulator. Refer to

GW-21, "Removal and Installation"

.

2. Remove bolts and front power window motor.

INSTALLATION

Installation is in the reverse order of removal.

REAR DOOR GLASS AND REGULATOR

GW-25

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

REAR DOOR GLASS AND REGULATOR

Exploded View

INFOID:0000000008969488

Removal and Installation

INFOID:0000000009429683

REAR DOOR GLASS

Removal

1. Remove rear door finisher. Refer to

INT-18, "Removal and Installation"

.

2. Remove vapor barrier. Refer to

GW-25, "Exploded View"

.

CAUTION:

Use care not to damage or tear vapor barrier during removal.

3. Temporarily reconnect the rear power window switch to raise/lower the rear door glass until the bolts can

be seen through the access holes (with power window).

4. Temporarily reinstall the rear door glass handle and raise/lower the rear door glass until the bolts can be

seen through the access holes (without power window).

1.

Rear door panel

2.

Vapor barrier

3.

Rear door glass front run

4.

Rear door glass

5.

Rear door glass rear run

6.

Rear door glass rubber run

7.

Rear door corner finisher

8.

Rear door glass regulator

9.

Rear power window motor

10. Rear door glass handle grommet

11. Rear door glass handle

A.

With power window

B.

Without power window

Clip

AWKIA2562ZZ
