ENGINE MAINTENANCE

MA-19

< PERIODIC MAINTENANCE >

Use Genuine RTV Silicone Sealant or equivalent. Refer to

8. Check engine oil level.
9. After warming up engine, check that there are no engine oil leaks with the engine running.
10. Install fender protector side cover (RH). Refer to

EXT-28, "FENDER PROTECTOR : Exploded View"

ENGINE OIL : Draining

INFOID:0000000011277776

WARNING:

• Be careful not to get burn yourself, as engine oil may be hot.

• Prolonged and repeated contact with used engine oil may cause skin cancer. Try to avoid direct skin

contact with used engine oil. If skin contact is made, wash thoroughly with soap or hand cleaner as

soon as possible.

1. Warm up the engine, and check for engine oil leaks from engine components. Refer to

MA-17, "ENGINE

OIL : Inspection"

2. Stop the engine and wait for 10 minutes.
3. Loosen oil filler cap.
4. Remove drain plug (1) and then drain engine oil.

ENGINE OIL : Refilling

INFOID:0000000011277777

1. Install drain plug with new drain plug washer. Refer to

EM-36, "Exploded View"

CAUTION:

Be sure to clean drain plug and install with new drain plug washer.

2. Refill with new engine oil.

Engine oil specification and viscosity: Refer to

MA-11, "Engine Oil Recommendation"

CAUTION:

• The refill capacity depends on the engine oil temperature and drain time. Use these specifica-

tions for reference only.

• Always use oil level gauge to determine the proper amount of engine oil in engine.

3. Warm up the engine and check area around drain plug and oil filter for engine oil leaks.
4. Stop the engine and wait for 5 minutes.
5. Check the engine oil level. Refer to

MA-17, "ENGINE OIL : Inspection"

OIL FILTER
OIL FILTER : Removal and Installation

INFOID:0000000011277778

REMOVAL

1. Remove fender protector side cover (RH). Refer to

EXT-28, "FENDER PROTECTOR : Exploded View"

Tightening torque

: Refer to

EM-97, "Exploded View"

: Front

JPBIA0889ZZ

Tightening torque : Refer to

EM-36, "Exploded View"

Engine oil capacity

: Refer to

LU-18, "Oil Capacity"

MA-20

< PERIODIC MAINTENANCE >

ENGINE MAINTENANCE

2. Drain engine oil. Refer to

MA-19, "ENGINE OIL : Draining"

3. Remove oil filter using suitable tool (A).

WARNING:

Be careful not to burn yourself, as engine oil may be hot.

CAUTION:

• When removing, prepare a shop cloth to absorb any

engine oil leaks or spills.

• Do allow engine oil to adhere to drive belt.

• Completely wipe off any engine oil that adheres to engine

and vehicle.

• Oil filter is provided with relief valve. Use genuine NISSAN

oil filter or equivalent.

INSTALLATION

1. Remove foreign materials adhering to oil filter installation surface.
2. Apply new engine oil to the oil seal contact surface of new oil fil-

ter.

3. Screw oil filter manually until it touches the installation surface,

then tighten it by 2/3 turn (A). Or tighten to the specification.

OIL FILTER : Inspection

INFOID:0000000011277779

INSPECTION AFTER INSTALLATION

1. Check the engine oil level. Refer to

MA-17, "ENGINE OIL : Inspection"

2. Start the engine, and check that there is are no leaks of engine oil.

: Front

JPBIA0890ZZ

ALC094

SMA010

Oil filter:

: 17.7 N·m (1.8 kg-m, 13 ft-lb)

JPBIA0077ZZ

ENGINE MAINTENANCE

MA-21

< PERIODIC MAINTENANCE >

3. Stop the engine and wait for at least 5 minutes.
4. Check the engine oil level, and adjust the level (if necessary). Refer to

MA-17, "ENGINE OIL : Inspection"

ENGINE COOLANT
ENGINE COOLANT : Inspection

INFOID:0000000011277780

LEVEL

• Check that the reservoir tank engine coolant level is within the

“MIN” to “MAX” when the engine is cool.

• Adjust the engine coolant level if necessary.

CAUTION:

Refill Genuine NISSAN Long Life Antifreeze/Coolant (blue) or

equivalent in its quality mixed with water (distilled or deminer-

alized). Refer to

MA-11, "Fluids and Lubricants"

CHECKING COOLING SYSTEM FOR LEAKS

• To check for leaks, apply pressure to the cooling system using suit-

able tools (A/B).

WARNING:

Do not remove the radiator cap when the engine is hot. Seri-

ous burns could occur from high-pressure engine coolant

escaping from the radiator. Wrap a thick cloth around the cap.

Slowly push down and turn it a quarter turn to allow built-up

pressure to escape. Carefully remove the cap by pushing it

down and turning it all the way.

CAUTION:

• Perform this step when the engine is cold.

• Do not spill engine coolant on drivebelt.

• Higher test pressure than specified may cause radiator damage.

NOTE:

• If engine coolant decreases, replenish radiator with engine coolant. Refer to

MA-11, "Fluids and Lubri-

cants"

• If anything is found, repair or replace damaged parts.

ENGINE COOLANT : Draining

INFOID:0000000011277781

WARNING:

Do not remove radiator cap when engine is hot. Serious burns could occur from high pressure engine

coolant escaping the radiator. Wrap a thick cloth around the cap. Slowly push down and turn it a quar-

ter turn to allow built-up pressure to escape. Carefully remove the cap by pushing it down and turning

it all the way.
1. Open radiator drain plug at the bottom of radiator, and then

remove radiator cap.

CAUTION:

• Do not allow engine coolant to contact the drive belt.

• Perform this step when the engine is cold.

(A)

: MAX

(B)

: MIN

JPBIA0102ZZ

Testing pressure

: Refer to

CO-25, "Radiator"

PBIC5121J

(A)

: Radiator drain plug hole

: Vehicle front

JPBIA0892ZZ

MA-22

< PERIODIC MAINTENANCE >

ENGINE MAINTENANCE

2. Follow this step for heater core removal/replacement only. Disconnect the upper heater hose at the

engine side and apply moderate air pressure [103.46 kPa (1.055 kg/cm

, 15 psi) maximum air pressure]

into the hose for 30 seconds to blow the excess engine coolant out of the heater core.

3. When draining all of the engine coolant in the system, remove the reservoir tank and drain the engine

coolant, then clean the reservoir tank before installation.

CAUTION:

• Do not allow the engine coolant to contact the drive belt.

• Perform this step when engine is cold.

4. When draining all of the engine coolant in the system for engine

removal or repair, remove the engine coolant drain plugs (A/B)

from the cylinder block.

5. Check the drained engine coolant for contaminants such as rust, corrosion or discoloration.

If the engine coolant is contaminated, flush the engine cooling system. Refer to

MA-24, "ENGINE COOL-

ANT : Flushing"

ENGINE COOLANT : Refilling

INFOID:0000000011277782

CAUTION:

• Do not put additive such as waterleak preventive, since it may cause cooling waterway clogging.

• When refilling use Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent in its quality

mixed with water (distilled or demineralized). Refer to

MA-11, "Fluids and Lubricants"

1. Install the radiator drain plug. Install the reservoir tank and cylin-

der block drain plug, if removed for a total system drain or for

engine removal or repair.

• The radiator must be completely empty of coolant and

water.

• Apply sealant to the threads of the cylinder block drain

plug.

• Use recommended coolant or equivalent.

Refer to

MA-11, "Fluids and Lubricants"

2. If disconnected, reattach the upper radiator hose at the engine side.
3. Set the vehicle heater controls to the full HOT and heater ON position. Turn the vehicle ignition ON with

the engine OFF as necessary to activate the heater mode.

AWBIA1957ZZ

Radiator drain plug

: Refer to

CO-13, "Exploded View"

Cylinder block drain plug (A)

: 53.9 Nm (5.5 kg-m, 40 ft-lb)

Cylinder block drain plug (B)

: 9.8 N·m (1.0 kg-m, 87 in-lb)

AWBIA1957ZZ
