DIAGNOSIS SYSTEM (BCM) (WITHOUT INTELLIGENT KEY SYSTEM)
COMMON ITEM
COMMON ITEM : CONSULT Function (BCM - COMMON ITEM)
INFOID:0000000011403308
APPLICATION ITEM
CONSULT performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions.
INT LAMP
INT LAMP : CONSULT Function (BCM - INT LAMP)
INFOID:0000000011403309
DATA MONITOR
Direct Diagnostic Mode
Description
Ecu Identification
The BCM part number is displayed.
Self Diagnostic Result
The BCM self diagnostic results are displayed.
Data Monitor
The BCM input/output data is displayed in real time.
Active Test
The BCM activates outputs to test components.
Work support
The settings for BCM functions can be changed.
Configuration
• The vehicle specification can be read and saved.
• The vehicle specification can be written when replacing BCM.
CAN Diag Support Mntr
The result of transmit/receive diagnosis of CAN communication is displayed.
System
Sub System
Direct Diagnostic Mode
E
cu
Id
en
tifi
ca
tio
n
Se
lf Di
ag
no
st
ic Re
su
lt
Da
ta
Mo
ni
tor
A
cti
ve
T
est
W
o
rk support
Co
nf
igu
rat
ion
CA
N Diag
Su
pp
ort Mn
tr
Door lock
DOOR LOCK
×
×
×
Rear window defogger
REAR DEFOGGER
×
×
×
Warning chime
BUZZER
×
×
Interior room lamp timer
INT LAMP
×
×
×
Remote keyless entry system
MULTI REMOTE ENT
×
Exterior lamp
HEADLAMP
×
×
Wiper and washer
WIPER
×
×
×
Turn signal and hazard warning lamps FLASHER
×
×
Combination switch
COMB SW
×
BCM
BCM
×
×
×
×
×
Immobilizer
IMMU
×
×
Interior room lamp battery saver
BATTERY SAVER
×
×
Back door open
TRUNK
×
Vehicle security system
THEFT ALM
×
×
×
RAP system
RETAINED PWR
×
TPMS
AIR PRESSURE MONITOR
×
×
×
×
