Nissan Rogue. Manual - part 730

FRONT REGULATOR

GW-17

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

5. Raise the front door glass and hold in place using a suitable tool

(A).

6. Disconnect the harness connector from the front power window motor.
7. Remove the bolts (A) and remove the front door glass regulator.

INSPECTION AFTER REMOVAL

Check the front door glass regulator for the following items:

• Wire wear

• Front door glass regulator deformation

• Grease condition for each sliding part

If a malfunction is detected, replace or grease it.

The arrows in the figure show the application points of the suitable

multi-purpose grease, if needed.

Inspection and Adjustment

INFOID:0000000011276514

INSTALLATION

Installation is in the reverse order of removal.

CAUTION:

• When the main power window and door lock/unlock switch or front power window and door lock/

unlock switch RH is removed it is necessary to perform the initialization procedure. Refer to

PWC-

28, "ADDITIONAL SERVICE WHEN REMOVING BATTERY NEGATIVE TERMINAL : Special Repair

Requirement"

.

• Tighten front door regulator bolts to specification. Refer to

GW-16, "Exploded View"

.

FITTING INSPECTION

• Check that the front door glass is fit securely into the glass run groove.

PIIB3510J

ALKIA2633ZZ

ALKIA3441ZZ

GW-18

< REMOVAL AND INSTALLATION >

FRONT REGULATOR

• Lower the front door glass slightly [approximately 10 to 20 mm (0.39 to 0.79) and check that the clearance to

the run is parallel.If the clearance between the glass and sash is not parallel, loosen the front door glass reg-

ulator bolts, front door glass run channel bolts, and glass and run rail bolts to correct the glass position.

FRONT POWER WINDOW MOTOR

GW-19

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

FRONT POWER WINDOW MOTOR

Removal and Installation

INFOID:0000000011276515

REMOVAL

1. Remove front door glass regulator. Refer to

GW-16, "Removal and Installation"

.

2. Remove screws (A) and front power window motor (1) from front

door glass regulator (2).

INSTALLATION

Installation is in the reverse order of removal.

ALKIA3443ZZ

GW-20

< REMOVAL AND INSTALLATION >

REAR DOOR GLASS

REAR DOOR GLASS

Exploded View

INFOID:0000000011276516

Removal and Installation

INFOID:0000000011276517

REMOVAL

1. Remove the rear door finisher. Refer to

INT-18, "Removal and Installation"

.

2. Remove the rear door vapor barrier (1).

3. Temporarily reconnect the rear power window switch.

1. Rear door panel

2. Rear door glass corner finisher

3. Rear door glass rear run channel

4. Rear door glass regulator assembly 5. Rear door glass power window motor 6. Rear door glass
7. Rear door glass rubber run channel

AWKIA3206ZZ

ALKIA3481ZZ
