DLN-100 < REMOVAL AND INSTALLATION > [REAR PROPELLER SHAFT: C-CVJ-C] REAR PROPELLER SHAFT REMOVAL AND INSTALLATION REAR PROPELLER SHAFT Exploded View INFOID:0000000011278392 Removal and Installation INFOID:0000000011278393 REMOVAL 1. Shift the transaxle to the neutral position, and then release the parking brake. EX-5, "Removal and Installation" . 3. Put matching marks onto propeller shaft flange yoke and final drive and transfer companion flanges. CAUTION: For matching marks, use paint. Do not damage propeller shaft flange yoke and transfer companion flange. Center bearing mounting bracket Clip Propeller shaft assembly Center bearing mounting bracket : Vehicle front : N·m (kg-m, ft-lb) : Always replace after every disassembly. JSDIA5323GB JSDIA0194ZZ |
