DAS ACTION TEST DAS-79 < BASIC INSPECTION > [DRIVER ASSISTANCE SYSTEM] C D E F G H I J K L M B N P A ACTION TEST LDW INFOID:0000000011277216 • Perform action test to verify the customer's concern. • Perform action test and check the system operation after system diagnosis. WARNING: Be careful of traffic conditions and safety around the vehicle when performing road test. CAUTION: • Fully understand the following items well before the road test; - Precautions: Refer to DAS-9, "Precautions for Driver Assistance Systems" . - System description for LDW: Refer to DAS-15, "LDW : System Description" - System description for BSW: Refer to DAS-19, "BSW : System Description" - System description for MOD: Refer to DAS-25, "MOD : System Description" - Handling precaution: Refer to DAS-35, "Precautions for Lane Departure Warning" . LDW : Inspection Procedure INFOID:0000000011277217 WARNING: Be careful of traffic conditions and safety around the vehicle when performing road test. CAUTION: • Fully understand the following items well before the road test; - Precautions: Refer to DAS-9, "Precautions for Driver Assistance Systems" . - System description for LDW: Refer to DAS-15, "LDW : System Description" - System description for BSW: Refer to DAS-19, "BSW : System Description" - System description for MOD: Refer to DAS-25, "MOD : System Description" - Handling precaution: Refer to DAS-35, "Precautions for Lane Departure Warning" . 1. CHECK LDW SYSTEM SETTING 1. Start the engine. 2. Check that the LDW system setting can be enabled/disabled on the vehicle information display. 3. Turn OFF the ignition switch and wait for 30 seconds or more. 4. Check that the previous setting is saved when the engine starts again. >> GO TO 2. 2. ACTION TEST FOR LDW 1. Enable the setting of the LDW system on the vehicle information display. 2. Turn warning systems switch ON (warning systems ON indicator is ON). 3. Check the LDW operation according to the following table. |
