AV-228 < SYSTEM DESCRIPTION > [NAVIGATION WITH BOSE] SYSTEM When A Call Is Originated • Spoken voice sound output from the microphone (microphone signal) is input to AV control unit. ® communication as a TEL voice signal. • Voice sound is then heard at the other party. When Receiving A Call • Voice sound is input to own cellular phone from the other party. ® communication from cellular phone, and the signal is output to front speakers. AROUND VIEW MONITOR FUNCTION • This system is equipped with wide-angle cameras on the front, rear and right and left door mirrors. • Images from front view, rear view, front-side view (RH side), and birds-eye view are displayed to monitor the vehicle surroundings. • Around view monitor control unit expands the image received from each camera to create each view. • In front view and rear view, the vehicle width, distance lines and predictive course lines are displayed. • In front-side view, the vehicle distance guiding line and vehicle width guiding line are displayed. • Birds-eye view converts the images from the cameras into an overhead view and displays the status of the vehicle on the display. The vehicle icon that is displayed in the birds-eye view is depicted by the around view monitor control unit. Display The around view monitor combines and displays travel direction view (front or rear), front-side view and birds- eye view. Operation • The around view monitor operates by pressing the CAMERA switch on the AV control unit or by shifting the selector lever to the R (reverse) position. • When the selector lever is in any position other than R (reverse) and the CAMERA switch is pressed, the screen displays front travel direction view and birds-eye view. Pressing the CAMERA switch again changes birds-eye view to front-side view • When the selector lever is placed in R (reverse), the screen displays rear travel direction view and birds-eye view. Pressing the CAMERA switch changes birds-eye view to front-side view • In birds-eye view, the blind spot area is displayed in black to show the border of the camera images. In addi- tion, red fixed lines are displayed in the 4 corners of the vehicle icon. After pressing the CAMERA switch for the first time or placing the selector lever in R (reverse) for the first time, the blind spot area is highlighted in yellow for 3 seconds and the red fixed lines blink five times. • With the selector lever in any position other than R (reverse), the around view monitor screen display is can- celled 3 minutes after pressing the CAMERA switch. The screen returns to the AV control unit display. • With the selector lever in R (reverse) position, the around view monitor screen display remains on con- stantly. To return to the AV control unit display, place the selector lever is in any position other than R (reverse). JSNIA3982GB |
