WARNING FUNCTION
DLK-43
< SYSTEM DESCRIPTION >
C
D
E
F
G
H
I
J
L
M
A
B
DLK
N
O
P
WARNING METHOD
The following table shows the alarm or warning methods with chime.
Meter display, “KEY” indicator or key slot illumination when the warning conditions are met.
Take away warning
Door is open to close
• Ignition switch: Except LOCK position.
• Door switch: ON to OFF (door is open to close).
• Intelligent Key cannot be detected inside the vehicle.
Door is open
• Door switch: ON (Door is open)
• Key ID verification every 5 seconds when registered Intelligent Key cannot
be detected inside the vehicle.
Push-ignition switch oper-
ation
• Ignition switch: Except LOCK position.
• Press ignition switch.
• Intelligent Key can not be detected inside the vehicle.
Take away through win-
dow
• Engine is running.
• Key ID verification every 30 seconds when registered Intelligent Key cannot
be detected inside the vehicle.
• After vehicle speed verification, the registered Intelligent Key cannot be de-
tect inside the vehicle.
Intelligent Key is removed
from key slot
• When Intelligent Key is removed from key slot, Intelligent Key cannot be de-
tected inside the vehicle.
Door lock operation warn-
ing
Request switch operation
When request switch is pushed (lock operation) under the following conditions.
• Door switch: ON (any door is open).
• Intelligent Key is inside vehicle.
Intelligent Key button op-
eration
When Intelligent Key button is pushed (lock operation) under the following con-
ditions.
• Door switch: ON (any door is open).
• For 3 seconds after Intelligent Key is removed from key slot.
Key warning
• Ignition switch is in OFF position.
• Driver side door switch: ON (driver side door is open).
• Intelligent Key is inserted in key slot.
Intelligent Key insert information
• Door switch: ON to OFF (door is open to close).
• Ignition switch: OFF to ON position.
• Intelligent Key is out of key slot.
• Intelligent Key cannot be detected inside the vehicle.
Engine start information
Ignition switch is in ON
position
• Ignition switch: ON position.
• Shift position: P position
• Engine is stopped
Ignition switch is except
ON position
• Ignition switch: Except ON position.
• Shift position: P position
• Intelligent Key is inserted in key slot.
• Intelligent Key can be detected inside the vehicle.
Intelligent Key low battery warning
When Intelligent Key has low battery, it is detected by BCM after ignition switch
is turned ON.
Key ID warning
When registered Intelligent Key cannot be detected inside the vehicle after ig-
nition switch is turned ON.
Warning/Information functions
Operation procedure
Warning/Information functions
“KEY” warn-
ing lamp
Combination meter display
Key slot il-
lumination
Warning chime
Combination
meter buzzer
Intelligent
Key warning
buzzer
Intelligent Key system malfunction
Illuminate
—
—
—
—
OFF position warn-
ing
For internal
—
—
—
Activate
—
For external
—
—
—
—
Activate
