AV-136
< ECU DIAGNOSIS INFORMATION >
[MONOCHROME DISPLAY - W/ BOSE]
BLUETOOTH® CONTROL UNIT
13
(P)
Ground
Ladder input 2
Input
ACC/ON
Press SOURCE
switch.
0 V
Press SEEK UP
switch.
0.7 V
Press SEEK DOWN
switch.
1.3 V
Press
switch.
2.0 V
Except for above.
3.3 V
14
(R)
-
Ladder ground
Input
-
-
-
17
(G)
Ground
Steering switch
signal A
Output
ON
Depress SOURCE
switch.
0V
Depress
switch.
0.7V
Depress
switch.
1.3V
Depress
switch.
2.0V
Except for above.
3.3V
18
(W)
Ground
Steering switch
signal B
Output
ON
Depress volume
DOWN switch.
0.7V
Depress volume UP
switch.
1.3V
Depress
switch.
2.0V
Except for above.
3.3V
19
(LG)
–
Steering switch
ground
Output
–
–
–
23
(B)
Gnd
Ground
–
–
–
0V
28
(BR)
–
Vehicle speed
signal (8-
pulse)
Input
ON
When vehicle speed
is approx. 25 MPH
(40 km/h)
29
(R)
Ground
Microphone
power
Output
ON
–
5V
33
(B)
–
Antenna
–
–
–
34
(B)
–
Antenna
–
–
–
35
(L)
–
M-CAN H1
–
–
–
36
(P)
–
M-CAN L1
–
–
–
37
–
Shield –
–
–
38
–
Shield –
–
–
Terminal
(Wire color)
Item
Signal
input/
output
Condition
Reference value
(Approx.)
+
–
Ignition
switch
Operation
PKIA1935E
