AV-96 < SYSTEM DESCRIPTION > [MONOCHROME DISPLAY - W/ BOSE] HANDS-FREE PHONE SYSTEM Component Description INFOID:0000000009471219 Part name Description Audio unit • Receives telephone voice signal from Bluetooth ® control unit. • Sends telephone voice and voice guidance signals to BOSE speaker amp. BOSE speaker amp. Inputs power (amp ON) and sound signal from audio unit, and outputs sound Door speaker Receives telephone voice and voice guidance signals from BOSE speaker Front tweeter Center speaker Steering wheel audio control switches • Start a voice recognition session Display unit • Receives display signal from Bluetooth ® control unit. • Displays audio system information. Microphone Sends voice signals to Bluetooth ® control unit. Bluetooth ® control unit Controls hands-free phone functions. Bluetooth ® antenna Sends telephone voice signal to Bluetooth ® control unit. |
