SERVICE DATA AND SPECIFICATIONS (SDS)
FSU-15
< SERVICE DATA AND SPECIFICATIONS (SDS)
C
D
F
G
H
I
J
K
L
M
A
B
FSU
N
O
P
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Front Wheel Alignment (Unladen*)
INFOID:0000000004523251
* : Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
Ball Joint
INFOID:0000000004523252
Wheelarch Height (Unladen*)
INFOID:0000000004523253
Unit: mm (in)
Camber*
Degree minute (decimal degree)
LH
Minimum
1
° 09' (-1.15°)
Nominal
-0
° 24' (-0.40°)
Maximum
0
° 21' (0.35°)
RH
Minimum
-1
° 24' (-1.40°)
Nominal
-0
° 39' (-0.65°)
Maximum
0
° 06' (0.10°)
Right and left difference
-0
° 15' ± 0° 33' (-0.25°± 0.55°)
Caster*
Degree minute (decimal degree)
Nominal
5
° 00' (5.00°)
Right and left difference
0
° 33' (0.55°)
Kingpin offset*
Degree minute (decimal degree)
Minimum
11
° 48' (11.80°)
Nominal
12
° 33' (12.55°)
Maximum
13
° 18' (13.30°)
Total toe-in*
Degree minute (decimal degree)
Distance
Minimum
0 mm (0 in)
Nominal
1 mm (0.04 in)
Maximum
2 mm (0.08 in)
Angle (right side or
left side)
Minimum
0
° 01' (0.017°)
Nominal
0
° 03' (0.050°)
Maximum
0
° 05' (0.083°)
Wheel turning angle*
Refer to
.
Swing torque
0.50 - 3.4 N·m (0.06 - 0.34 kg-m, 5 - 30 in-lb)
Measurement on tool
7.94 - 53.97 N (0.81 - 5.50 kg, 1.79 - 12.2 lb)
Rotating torque
0.50 - 3.4 N·m (0.06 - 0.34 kg-m, 5 - 30 in-lb)
Axial endplay
0.1 mm (0.004 in) or less
Destination
USA
Canada
Tire size
215/60R16
215/60R16
SFA818A
