Nissan Altima HL32 Hybrid. Manual - part 162





BRM-2

< FEATURES OF NEW MODEL >

BODY EXTERIOR PAINT COLOR

FEATURES OF NEW MODEL

BODY EXTERIOR PAINT COLOR

Body Exterior Paint Color

INFOID:0000000004216212

M= Metallic, S= Solid, 2S= Solid and Clear, 2P= 2-stage Pearl, 3P= 3-Stage pearl, PM=Pearl metallic, Black is solvent based, all others
are water based.

AWKIA1257ZZ

Component

Color code

NAC

RAB

HAB

DAD

K12

K50

KH3

QX3

W40

Description

Red

Blue

Beige

Grey -
Green

Silver

Dark
Grey

Black

White

Medium

Grey

Paint type

M

M

M

M

M

M

2S

3P

M

Hard clear
coat

×

×

×

×

x

×

×

×

×

1

Bumper fas-
cia

Body color

NAC

RAB

HAB

DAD

K12

K50

KH3

 QX3

W40

2 Front grille

Chromium-
plate
+ Smoke clear

Cr

+ HFM-

09

Cr

+ HFM-

09

Cr

+ HFM-

09

Cr

+ HFM-

09

Cr

+ HFM-

09

Cr

+ HFM-

09

Cr

+ HFM-

09

   Cr
+ HFM-
09

Cr

+ HFM-

09

3

Door outside
mirror

Case

Body color

NAC

RAB

HAB

DAD

K12

K50

KH3

QX3

W40

4

Body side
molding

Body color

NAC

RAB

HAB

DAD

K12

K50

KH3

QX3

W40

5

License plate
finisher

Chromium-
plate
+ body color

Cr +

NAC

CR +

RAB

Cr +

HAB

Cr +

DAD

Cr +

K12

Cr +

K50

Cr +
KH3

Cr +

QX3

Cr +

W40

6

Door outside
handle

Body color

NAC

RAB

HAB

DAD

K12

K50

KH3

QX3

W40

7

Fuel filler
lid

Body color

NAC

RAB

HAB

DAD

K12

K50

KH3

QX3

W40

HANDLING PRECAUTIONS FOR PLASTICS

BRM-3

< PRECAUTION >

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

PRECAUTION

HANDLING PRECAUTIONS FOR PLASTICS

Precautions For Plastics

INFOID:0000000004216213

1. When repairing and painting a portion of the body adjacent to plastic parts, consider their characteristics

(influence of heat and solvent) and remove them if necessary or take suitable measures to protect them.

2. Plastic parts should be repaired and painted using methods suiting the materials

,

 characteristics.

LOCATION OF PLASTIC PARTS

Abbre-

viation

Material name

Heat resisting

temperature

°C(°F)

Resistance to gasoline and

solvents

Other cautions

PE

Polyethylene

60(140)

Gasoline and most solvents are
harmless if applied for a very
short time (wipe up quickly).

Flammable

PVC

Poly Vinyl Chloride

80(176)

Same as above.

Poison gas is emitted
when burned.

EPM/
EPDM

Ethylene Propylene (Diene) co-
polymer

80(176)

Same as above.

Flammable

PP

Polypropylene

90(194)

Same as above.

Flammable, avoid bat-
tery acid.

UP

Unsaturated Polyester

90(194)

Same as above.

Flammable

PS

Polystyrene

80(176)

Avoid solvents.

Flammable

ABS

Acrylonitrile Butadiene Styrene

80(176)

Avoid gasoline and solvents.

PMMA

Poly Methyl Methacrylate

85(185)

Same as above.

EVAC

Ethylene Vinyl Acetate

90(194)

Same as above.

ASA

Acrylonitrile Styrene Acrylate

100(222)

Same as above.

Flammable

PPE

Poly Phenylene Ether

110(230)

Same as above.

PC

Polycarbonate

120(248)

Same as above.

PAR

Polyarylate

180(356)

Same as above.

PUR

Polyurethane

90(194)

Same as above.

POM

Poly Oxymethylene

120(248)

Same as above.

Avoid battery acid.

PBT+
PC

Poly Butylene Terephthalate +
Polycarbonate

120(248)

Same as above.

Flammable

PA

Polyamide

140(284)

Same as above.

Avoid immersing in wa-
ter.

PBT

Poly Butylene Terephthalate

140(284)

Same as above.

PET

Polyester

180(356)

Same as above.

PEI

Polyetherimide

200(392)

Same as above.

BRM-4

< PRECAUTION >

HANDLING PRECAUTIONS FOR PLASTICS

Item

Component

Abbreviation

Material

1.

Door Mirror

Case

ASA

Acronitrile Styrene Acrylate

Skull cap

ABS

Acronitrile Butadiene Acrylate

2.

Outside door handle

Grip

PC

Polycarbonate

Escutcheon

PA

Polyamide (Nylon)

ALKIA1368ZZ

HANDLING PRECAUTIONS FOR PLASTICS

BRM-5

< PRECAUTION >

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

3.

Front combination lamp

Lens

PC

Polycarbonate

Housing

PP

Polypropylene

4.

Front bumper fascia

PP + EPM

Polypropylene + Ethylene Propylene (Diene)
copolymer

5.

Rear combination lamp

Lens

PMMA

Poly Methyl Methacrylate

Housing

ABS

Acronitrile Butadiene Acrylate

6.

Rear bumper fascia

PP + EPM

Polypropylene + Ethylene Propylene (Diene)
copolymer

7.

Trunk lid finisher

ABS + PC

Acronitrile Butadiene Acrylate + Polycarbon-
ate

Item

Component

Abbreviation

Material

Item

Component

Abbreviation

Material

1.

Center pillar trim

PP

Polypropylene

2.

Upper quarter trim

PP

Polycarbonate

3.

Rear inner kicking plate

PP

Polypropylene

4.

Front inner kicking plate

PP

Polypropylene

5.

Dash side finisher

PP

Polypropylene

6.

Front pillar garnish

PP

Polypropylene

7.

Steering column covers

PP

Polypropylene

ALKIA1369ZZ
