FSU-24

< SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)

General Specification (Front)

INFOID:0000000009478847

Spring Free Height

INFOID:0000000009478848

VQ40DE

Unit: mm (in)

QR25DE

Unit: mm (in)

Wheel Alignment (Unladen*1)*6

INFOID:0000000009478849

Suspension type

Independent double wishbone coil over shock

Shock absorber type

Double-acting hydraulic

Stabilizer

Standard equipment

Drive type

2WD

4WD

Front spring free height - short wheel base

336 (13.23)

346 (13.62)

Front spring free height - long wheel base

337.1 (13.27)

346 (13.62)

Front spring free height

346 (13.62)

Drive type

2WD

4WD

Camber
Degree minute (decimal degree)

Minimum

-0

° 30′ (-0.50°)

-0

° 15′ (-0.25°)

Nominal

0

° 15′ (0.25°)

0

° 30′ (0.50°)

Maximum

1

° 0′ (1.00°)

1

° 15′ (1.25°)

Cross camber

0

° 45′ (0.75°) or less

 0

° 45′ (0.75°) or less

Caster
Degree minute (decimal degree)

Minimum

2

° 00′ (2.00°)

1

° 45′ (1.75°)

Nominal

2

° 45′ (2.75°)

2

° 30′ (2.5°)

Maximum

3

° 30′ (3.50°)

3

° 15′ (3.25°)

Cross caster

0

° 45′ (0.75°) or less

0

° 45′ (0.75°) or less

Kingpin inclination
Degree minute (decimal degree)

Nominal

13

° 0′ (13.00°)

12

° 45′ (12.75°)

Total toe-in

Distance

Minimum

In 3.0 mm (In 0.12 in)

Nominal

In 4.0 mm (In 0.16 in)

Maximum

In 5.0 mm (In 0.20 in)

Angle
Degree minute (Decimal degree)

Minimum

In 0

° 7′ (In 0.12°)

Nominal

In 0

° 9′ (In 0.15°)

Maximum

In 0

° 11′ (In 0.18°)

SFA234AC

SERVICE DATA AND SPECIFICATIONS (SDS)

FSU-25

< SERVICE DATA AND SPECIFICATIONS (SDS)

C

D

F

G

H

I

J

K

L

M

A

B

FSU

N

O

P

*1: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
*2: Target value 35

° 28′ (35.47°)

*3: Target value 31

° 27′ (31.45°)

*4: Target value 35

° 38′ (35.63°)

*5: Target value 31

° 49′ (31.82°)

*6: Some vehicles may be equipped with straight (non-adjustable) lower link bolts and washers. In order to adjust camber and caster on
these vehicles, first replace the lower link bolts and washers with adjustable (cam) bolts and washers.

Ball Joint

INFOID:0000000009478850

Wheelarch Height (Unladen*

1

)

INFOID:0000000009478851

King Cab

Unit: mm (in)

Wheel turning angle (full turn)

Inside
Degree minute (Decimal degree)

33

° 28′– 35° 28′ *

2

(33.47

°– 35.47°)

33

° 38′– 35° 38′ *

4

(33.63

°– 35.63°)

Outside
Degree minute (Decimal degree)

29

° 27′– 31° 27′ *

3

(29.45

°– 31.45°)

29

° 49′– 31° 49′ *

5

(29.82

°– 31.82°)

Drive type

2WD

4WD

Swinging force (A)
(Measurement point at either cotter pin hole or groove of ball
stud.)

Upper

8.1 - 79 N (0.83 - 8.1 kg-f, 1.82 - 17.8 lb-f) at hole

Lower

11.4 - 145.5 N (1.16 - 14.84 kg-f, 2.56 - 32.71 lb-f) at groove

Turning torque (B)

Upper

0.5 - 4.9 N·m (0.05 - 0.49 kg-m, 5 - 43 in-lb)

Lower

0.5 - 6.4 N·m (0.05 - 0.65 kg-m, 5 - 56 in-lb)

Vertical end play (C)

0 mm (0 in)

SFA858A

WEIA0076E

Drive type

2WD

4WD

Engine type

QR25DE

VQ40DE

Tire size

P235/75R15

P265/70R16

P265/70R16

P265/75R16

P265/70R16

P265/75R16

LEIA0085E

FSU-26

< SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)

*1: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.

Crew Cab

Unit: mm (in)

*1: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.

Front wheelarch height (Hf)

850

(33.46)

865

(34.06)

868

(34.17)

880

(34.65)

881

(34.68)

893

(35.16)

Rear wheelarch height (Hr)

878

(34.57)

887

(34.92)

895

(35.24)

907

(35.71)

904

(35.59)

917

(36.10)

Engine type

VQ40DE

Drive type

2WD

4WD

Tire size

P265/70R16

P265/75R16

P265/60R18

P265/70R16

P265/75R16

P265/60R18

Wheel base

Short

Long

Short

Short

Long

Short

Long

Short

Short

Long

Front
wheelarch
height (Hf)

867

(34.13)

870

(34.25)

879

(34.61)

866

(34.09)

869

(34.21)

879

(34.61)

882

(34.72)

891

(35.08)

879

(34.61)

882

(34.72)

Rear
wheelarch
height (Hr)

892

(35.12)

892

(35.12)

904

(35.59)

892

(35.12)

892

(35.12)

905

(35.63)

902

(35.51)

918

(36.14)

905

(35.63)

902

(35.51)

LEIA0085E

A
B

C

D

E

F

G

H

I

J

K

L

M

N

P

O

QUICK REFERENCE INDEX



A GENERAL INFORMATION

GI

General Information

B ENGINE

EM

Engine Mechanical

LU

Engine Lubrication System

CO

Engine Cooling System

EC

Engine Control System

FL

Fuel System

EX

Exhaust System

STR

Starting System

ACC

Accelerator Control System

C HYBRID

HBC

Hybrid Control System

HBB

Hybrid Battery System

D TRANSMISSION & DRIVE-

LINE

CL

Clutch

TM

Transaxle & Transmission

DLN

Driveline

FAX

Front Axle

RAX

Rear Axle

E SUSPENSION

FSU

Front Suspension

RSU

Rear Suspension

SCS

Suspension Control System

WT

Road Wheels & Tires

F BRAKES

BR

Brake System

PB

Parking Brake System

BRC

Brake Control System

G STEERING

ST

Steering System

STC

Steering Control System

H RESTRAINTS

SB

Seat Belt

SBC

Seat Belt Control System

SR

SRS Airbag

SRC

SRS Airbag Control System

I VENTILATION, HEATER &

AIR CONDITIONER

VTL

Ventilation System

HA

Heater & Air Conditioning System

HAC

Heater & Air Conditioning Control System

J BODY INTERIOR

INT

Interior

IP

Instrument Panel

SE

Seat

ADP

Autodrive Positioner System

AP

Adjustable Pedals

K BODY EXTERIOR,

DOORS, ROOF & VEHICLE

SECURITY

DLK

Door & Lock

SEC

Security Control System

GW

Glass & Window System

PWC

Power Window Control System

RF

Roof

EXT

Exterior

BRM

Body Repair Manual

L DRIVER CONTROLS

MIR

Mirrors

EXL

Exterior Lighting System

INL

Interior Lighting System

WW

Wiper & Washer

DEF

Defogger

HRN

Horn

M ELECTRICAL & POWER

CONTROL

PWO

Power Outlet

BCS

Body Control System

LAN

LAN System

PCS

Power Control System

CHG

Charging System

PG

Power Supply, Ground & Circuit Elements

N DRIVER INFORMATION &

MULTIMEDIA

MWI

Meter, Warning Lamp & Indicator

WCS

Warning Chime System

SN

Sonar System

AV

Audio, Visual & Navigation System

O CRUISE CONTROL

CCS

Cruise Control System

P MAINTENANCE

MA

Maintenance
