Nissan Frontier. Manual - part 92

AV-360

< REMOVAL AND INSTALLATION >

[NAVIGATION]

SATELLITE RADIO ANTENNA

SATELLITE RADIO ANTENNA

Removal and Installation

INFOID:0000000009482264

REMOVAL

1. Remove the roof console. Refer to

INT-25, "Removal and Installation"

.

2. Disconnect the harness connector from the satellite radio antenna.
3. Remove the satellite radio antenna nut.
4. Remove the satellite radio antenna.

INSTALLATION

Installation is in the reverse order of removal.

LKIA0679E

AV

GPS ANTENNA

AV-361

< REMOVAL AND INSTALLATION >

[NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

GPS ANTENNA

Removal and Installation

INFOID:0000000009482265

REMOVAL

1. Remove the combination meter. Refer to

MWI-90, "Removal and Installation"

.

2. Remove the GPS antenna screw and the GPS antenna.

INSTALLATION

Installation is in the reverse order of removal.

AV-362

< REMOVAL AND INSTALLATION >

[NAVIGATION]

USB CONNECTOR

USB CONNECTOR

Removal and Installation

INFOID:0000000009482266

REMOVAL

1. Remove the center console assembly. Refer to

IP-26, "Removal and Installation"

.

2. Push the pawl from the back of the center console to remove the USB interface.

INSTALLATION

Installation is in the reverse order of removal.

AV

REAR VIEW CAMERA

AV-363

< REMOVAL AND INSTALLATION >

[NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

REAR VIEW CAMERA

Removal and Installation

INFOID:0000000009482267

REMOVAL

1. Remove the tail gate protector. Refer to

EXT-38, "Removal and Installation"

.

2. Remove the rear view camera screws and the rear view camera.

INSTALLATION

Installation is in the reverse order of removal.
