AV-352

< REMOVAL AND INSTALLATION >

[NAVIGATION]

REAR DOOR SPEAKER

REAR DOOR SPEAKER

Removal and Installation

INFOID:0000000009482256

REMOVAL

1. Remove the rear door finisher. Refer to

INT-15, "Removal and Installation"

.

2. Remove the rear door speaker screws (A).
3. Disconnect the harness connector (B) from the rear door

speaker (1) and remove.

INSTALLATION

Installation is in the reverse order of removal.

ALNIA0348ZZ

AV

REAR TWEETER

AV-353

< REMOVAL AND INSTALLATION >

[NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

REAR TWEETER

Removal and Installation

INFOID:0000000009482257

REMOVAL

1. Remove the rear door finisher. Refer to

INT-15, "Removal and Installation"

.

2. Remove the rear door tweeter screws (A) and rear door tweeter

(1).

INSTALLATION

Installation is in the reverse order of removal.

ALNIA0351ZZ

AV-354

< REMOVAL AND INSTALLATION >

[NAVIGATION]

SUBWOOFER

SUBWOOFER

Removal and Installation

INFOID:0000000009482258

REMOVAL

1. Position the LH rear seat cushion in the folded up position.
2. Remove storage box (RH) (crew cab). Refer to

INT-23, "Removal and Installation"

.

3. Remove the subwoofer screws.
4. Disconnect the harness connector from the subwoofer and remove.

INSTALLATION

Installation is in the reverse order of removal.

1.

Subwoofer

2.

Bracket

3.

Locating pin plate

4.

Locating pin

5.

Connector

LKIA0639E

AV

STEERING SWITCH

AV-355

< REMOVAL AND INSTALLATION >

[NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

STEERING SWITCH

Removal and Installation

INFOID:0000000009482259

Removal and Installation

REMOVAL

1. Remove the driver air bag module. Refer to

SR-11, "Removal and Installation"

.

2. Remove the steering wheel audio control switch assembly screws.
3. Disconnect the harness connectors from the steering wheel audio control switches.
4. Remove the steering wheel audio control switches by pulling on

steering wheel audio control switches to release the pawls.

: Pawl

CAUTION:

Do not tilt steering wheel audio control switches during

removal or damage may occur to the pawls.

INSTALLATION

Installation is in the reverse order of removal.

1. Steering wheel

2.

Steering wheel audio control switches

ALNIA0357ZZ

ALNIA1214ZZ
