AV

BOSE AMP.

AV-387

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION WITH BOSE]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

BOSE AMP.

Reference Values

INFOID:0000000010122632

TERMINAL LAYOUT

PHYSICAL VALUES

AWNIA3472ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Power
switch

Operation

1

(R)

5

(G)

Sound signal rear door
speaker LH

Output

ON

Sound output

4

(R)

Ground Battery power supply

Input

OFF

—

Battery voltage

6

(P)

2

(L)

Sound signal subwoofer

Output

ON

Sound output

8

(B)

—

Ground

—

ON

—

0

V

9

(G)

17

(R)

Sound signal front door
speaker LH

Output

ON

Sound output

10

(P)

11

(L)

Sound signal front door
speaker RH

Output

ON

Sound output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

AV-388

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION WITH BOSE]

BOSE AMP.

13

(G)

12

(R)

Sound signal tweeter LH

Output

ON

Sound output

15

(V)

14

(SB)

Sound signal tweeter RH

Output

ON

Sound output

16

(L)

24

(P)

Sound signal rear door
speaker RH

Output

ON

Sound output

22

(L)

Ground BOSE amp. ON signal

Input

ON

—

Battery voltage

27

(BR)

35

(Y)

Pre amp sound signal rear
RH

Input

ON

Sound output

29

(G)

37

(R)

Pre amp sound signal front
RH

Input

ON

Sound output

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Power
switch

Operation

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

AV

BOSE AMP.

AV-389

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION WITH BOSE]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

36

(LG)

28

(V)

Pre amp sound signal rear
LH

Input

ON

Sound output

38

(W)

30

(B)

Pre amp sound signal front
LH

Input

ON

Sound output

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Power
switch

Operation

SKIB3609E

SKIB3609E

AV-390

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION WITH BOSE]

AROUND VIEW MONITOR CONTROL UNIT

AROUND VIEW MONITOR CONTROL UNIT

Reference Value

INFOID:0000000010122633

VALUES ON THE DIAGNOSIS TOOL

TERMINAL LAYOUT

PHYSICAL VALUES

Monitor Item

Condition

Value/Status

CAMERA OFF SIGNAL

CAMERA switch ON.

Off

CAMERA switch OFF.

On

CAMERA SWITCH SIGNAL

CAMERA switch OFF.

Off

CAMERA switch ON.

On

DR-SIDE CAMERA IMAGE SIG

Side camera LH inoperative.

NG

Side camera LH operative.

OK

F-CAMERA IMAGE SIG

Front camera inoperative.

NG

Front camera operative.

OK

PA-SIDE CAMERA IMAGE SIG

Side camera RH inoperative.

NG

Side camera RH operative.

OK

REAR CAMERA IMAGE SIGNAL

Rear camera LH inoperative.

NG

Rear camera LH operative.

OK

REVERSE SIGNAL

When selector lever is in any position other than R (reverse).

Off

When selector lever in R (reverse).

On

ST ANGLE SENSOR SIGNAL

Around view monitor control unit is not receiving steering angle
sensor signal.

Off

Around view monitor control unit is receiving steering angle sen-
sor signal.

On

ST ANGLE SENSOR TYPE

Steering angle sensor type.

Absolute

ST GEAR RATIO TYPE

Steering gear ratio type.

Type O

STEERING POSITION

Left hand drive vehicle.

LHD

Right hand drive vehicle.

RHD

VEHICLE SPEED SIGNAL

While driving, equivalent to speedometer reading

mph, km/h
