Nissan Primera P11. Manual - part 548





STEERING SYSTEM

SECTION

ST

CONTENTS

PRECAUTIONS AND PREPARATION

.......................... 2

Precautions ................................................................ 2
Preparation ................................................................ 2

PREPARATION

.............................................................. 3

NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING

................................................... 4

NVH Troubleshooting Chart....................................... 4

ON-VEHICLE INSPECTION

.......................................... 5

Checking Steering Wheel Play.................................. 5
Checking Neutral Position on Steering Wheel .......... 5
Front Wheel Turning Angle........................................ 5
Checking Gear Housing Movement .......................... 5
Checking and Adjusting Drive Belts .......................... 6
Checking Fluid Level ................................................. 6
Checking Fluid Leakage ............................................ 6
Bleeding Hydraulic System........................................ 6
Checking Steering Wheel Turning Force .................. 7
Checking Hydraulic System....................................... 8

STEERING WHEEL AND STEERING COLUMN

.......... 9

Removal and Installation ......................................... 10
Disassembly and Assembly......................................11
Inspection................................................................. 12

POWER STEERING GEAR AND LINKAGE

.............. 14

Removal and Installation ......................................... 14
Disassembly............................................................. 17
Inspection................................................................. 17
Assembly ................................................................. 19

SR20DE

POWER STEERING OIL PUMP

.................................. 20

CD20T

POWER STEERING OIL PUMP

.................................. 21

QG16, 18DE

POWER STEERING OIL PUMP

.................................. 22

SR20DE, CD20T, QG16DE, QG18DE

SERVICE DATA AND SPECIFICATIONS (SDS)

........ 23

General Specifications............................................. 23
Inspection and Adjustment ...................................... 23

ST

Precautions

Supplemental Restraint System (SRS) “AIR BAG”
and “SEAT BELT PRE-TENSIONER”

The Supplemental Restraint System “Air Bag” and “Seat Belt Pre-tensioner”, used along with a seat belt,
help to reduce the risk or severity of injury to the driver and front passenger in a frontal collision. The
Supplemental Restraint System consists of air bag modules (located in the center of the steering wheel and
on the instrument panel on the passenger side), seat belt pre-tensioners, a diagnosis sensor unit, warning
lamp, wiring harness and spiral cable.
If the vehicle is equipped with side air bag as the Supplemental Restraint System, the side air bag used along
with the seat belt helps to reduce the risk or severity of injury to the driver and front passenger in a side
collision. The side air bag consists of air bag modules (located in the outer side of front seats), satellite
sensor, diagnosis sensor unit (which is one of components of air bags for a frontal collision), wiring harness,
warning lamp (which is one of components of air bags for a frontal collision).

WARNING:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
(in the event of a collision which would result in air bag inflation), all maintenance must be per-
formed by an authorized NISSAN dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to do so
in this Service Manual. SRS wiring harnesses are covered with yellow insulation (either just
before the harness connectors or for the complete harness), for easy identification.

STEERING SYSTEM

Before disassembly, thoroughly clean the outside of the unit.

Disassembly should be done in a clean work area. It is important to prevent the internal parts
from becoming contaminated by dirt or other foreign matter.

When disassembling parts, be sure to place them in order on a part rack so they can be rein-
stalled in their correct positions.

Only use nylon cloths or paper towels to clean parts. Do not use rags or other materials contain-
ing lint. Residual debris may damage the system.

Before inspection or reassembly, carefully clean all parts with a general purpose, non-flammable
solvent.

Before assembly, apply a coat of recommended ATF* to hydraulic parts. Vaseline may be applied
to O-rings and seals. Do not use any grease.

Replace all gaskets, seals and O-rings. Avoid damaging O-rings, seals and gaskets during instal-
lation. Perform functional tests whenever designated.
*: Automatic transmission fluid

Preparation

SPECIAL SERVICE TOOL

Tool number
Tool name

Description

ST27180001
Steering wheel puller

NT170

Removing and installing steering wheel

PRECAUTIONS AND PREPARATION

ST-2

SPECIAL SERVICE TOOLS

Tool number
Tool name

Description

KV48100700
Torque adapter

Measuring pinion rotating torque

HT72520000
Ball joint remover

Removing ball joint

ST27091000
Pressure gauge

Measuring oil pressure

KV48102500
Pressure gauge adapter

Measuring oil pressure

ST3127S000

p

1

GG91030000

Torque wrench

p

2

HT62940000

Socket adapter

p

3

HT62900000

Socket adapter

Measuring turning torque

PREPARATION

ST-3

NVH Troubleshooting Chart

Use the chart below to help you find the cause of the symptom.
If necessary, repair or replace these parts.

Reference page

ST

-6

ST

-6

ST

-18

ST

-18

ST

-19

ST

-6

ST

-5

ST

-7

Refer

to

MA

section.

ST

-12

ST

-5

ST

-13

ST

-1

1

ST

-14

NVH

in

F

A

section

NVH

in

F

A

,

R

A

section

NVH

in

F

A

section

NCH

in

F

A

section

NVH

in

BR

section

Possible cause and
SUSPECTED PARTS

Fluid

level

Air

in

hydraulic

system

T

ie-rod

ball

joint

swinging

force

T

ie-rod

ball

joint

rotating

torque

T

ie-rod

ball

joint

end

play

Steering

gear

fluid

leakage

Steering

wheel

play

Steering

wheel

turning

force

Drive

belt

looseness

Improper

steering

wheel

Improper

installation

or

looseness

of

tilt

lock

lever

Mounting

rubber

deterioration

Steering

column

deformation

or

damage

Improper

installation

or

looseness

of

steering

column

Steering

linkage

looseness

DRIVE

SHAFT

AXLE

AND

SUSPENSION

TIRES

ROAD

WHEEL

BRAKES

Symptom

STEERING

Noise

X

X

X

X

X

X

X

X

X

X

X

X

X

X

Shake

X

X

X

X

X

X

X

X

Vibration

X

X

X

X

X

X

X

X

Shimmy

X

X

X

X

X

X

X

X

Judder

X

X

X

X

X

X

X: Applicable

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

ST-4
