Nissan Primera P11. Manual - part 319
YEL166C
A/C CONTROL
PANEL
HEATER ILLUMI-
NATION
.
ELECTRIC SPEEDOMETER
TACHOMETER
WATER TEMPERATURE GAUGE
FUEL GAUGE
FUEL WARNING LAMP
TRIP COMPUTER:
TC
OUTSIDE AIR TEMPERATURE GAUGE:
OG
COMBINATION
METER
: With CVT
: With M/T
: With air conditioner
: Without air conditioner
: With GA engine
: With SR engine or QG engine
: With gasoline engine
: With diesel engine
: With trip computer
: With outside air temperature gauge
THERMAL TRANS-
MITTER
FUEL LEVEL
SENSOR UNIT
REFER TO THE FOLLOWING
ELECTRICAL UNITS
ELECTRICAL UNITS
METER AND GAUGES
Wiring Diagram — METER —/MODELS
BEFORE VIN - P11U0548750 (Cont’d)
EL-143
