Service Data and Specifications (SDS)
ALTERNATOR
Type
A2TB3691
A2TB3891
LR180-762
LR190-734E
MITSUBISHI
HITACHI
Applied model
SR20, MT
SR20, CVT
QG18, QG16
CD20T
Nominal rating
V-A
12-80
12-90
12-80
12-90
Ground polarity
Negative
Minimum revs under no-
load (When 13.5V is
applied)
rev/min
Less than 1,300
Less then 1,000
Hot output current
(when 13.5V is applied)
A/rev/min
More than 23/1,300
More than 64/2,500
More than 82/5,000
More than 22/1,300
More than 64/2,500
More than 85/5,000
More than 23/1,300
More than 65/2,500
More than 87/5,000
More than 32/1,300
More than 54/2,500
More than 87/5,000
Regulated output
voltage
V
14.1 - 14.7
Brush minimum length
mm (in)
5.0 (0.197)
6.0 (0.236)
Brush spring pressure
N (g, oz)
4.8 - 6.0 (490 - 610, 17.28 - 21.51)
1.0 - 3.43
(102 - 350,
3.60 - 12.34)
Slip ring minimum diameter
mm (in)
22.1 (0.870)
26.0 (1.024)
Rotor coil resistance at
20°C (68°F)
2.2 - 2.6
1.8 - 2.1
2.67
2.60
CHARGING SYSTEM
EL-63
