RFD-4

[C200]

PREPARATION

KV38100600
(J25267)
Side bearing spacer drift

Installing side bearing spacer
a: 8 mm (0.31 in)
b: R42.5 mm (1.673 in)

ST30611000
(J25742-1)
Drift

Installing pinion rear bearing outer race

ST30621000
(J25742-5)
Drift

Installing pinion rear bearing outer race
a: 79 mm (3.11 in) dia.
b: 59 mm (2.32 in) dia.

ST30613000
(J25742-3)
Drift

Installing pinion front bearing outer race
a: 72 mm (2.83 in) dia.
b: 48 mm (1.89 in) dia.

KV38100500
(J25273)
Gear carrier front oil seal drift

Installing front oil seal
a: 85 mm (3.35 in) dia.
b: 60 mm (2.36 in) dia.

(J34309)
Differential shim selector

Adjusting bearing pre-load and gear height

(J25269-4)
Side bearing discs
(2 Req'd)

Selecting pinion height adjusting washer

Tool number
(Kent-Moore No.)
Tool name

Description

NT528

NT090

NT073

NT073

NT115

NT134

NT136

PREPARATION

RFD-5

[C200]

C

E

F

G

H

I

J

K

L

M

A

B

RFD

(J8129)
Spring gauge

Measuring carrier turning torque

KV381051S0
(

—

)

Rear axle shaft dummy
1 KV38105110
(

—

)

Torque wrench side
2 KV38105120
(

—

)

Vise side

Checking differential torque on limited slip dif-
ferential

KV10112100
(BT8653-A)
Angle wrench

Tightening side bearing cap bolts

Tool number
(Kent-Moore No.)
Tool name

Description

NT127

NT142

S-NT014

RFD-6

[C200]

NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTING

NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTING

PFP:00003

NVH Troubleshooting Chart

EDS0012Q

Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.

×: Applicable

Reference page



RFD-2

1

 ,

RFD-

2

1

RFD-2

0

RFD-2

0

RFD-1

4

—

MA

-1

2

PR-

3

FA

X

-4

,

RAX-

5

 ,

FSU-

4

 ,

RSU-4

WT

-3

RAX-

5

BR-

6

PS-

5

Possible cause and SUSPECTED PARTS

R

o

ugh gea

r t

o

ot

h

Im

pr

o

per

 g

ear

 co

nt

act

T

oot

h sur

fac

e w

o

rn

In

c

o

rr

e

c

t b

a

c

k

la

s

h

C

o

m

pani

on f

lan

ge exce

ssi

ve r

unou

t

Im

pr

o

per

 g

ear

 oi

l

PROPEL

LER SHAFT

AXL

E AND

SUSPENSION

TIRES

ROAD W

H

EE

L

DRIVESHAFT

BRAKE

S

ST

EERI

N

G

Symptom

DIFFERENTIAL

Noise

×

×

×

×

×

×

×

×

×

×

×

×

×

FRONT OIL SEAL

RFD-7

[C200]

C

E

F

G

H

I

J

K

L

M

A

B

RFD

FRONT OIL SEAL

PFP:38189

Removal and Installation

EDS0012R

1.

Remove propeller shaft. Refer to

PR-8, "Removal and Installation"

 .

2.

Loosen drive pinion nut while holding companion flange using
Tool.

3.

Remove companion flange using a suitable tool.

4.

Remove ABS sensor and rear wheel sensor rotor.

5.

Remove front oil seal.

6.

Apply multi-purpose grease to cavity at sealing lips of oil seal.
Press front oil seal into carrier using Tool.

7.

Install ABS sensor and rear wheel sensor rotor.

8.

Install companion flange.

Tool number

: KV38108300 (J-44195)

APD032

SPD737

WPD013

Tool number

: KV38100500 (J25273)

ABS sensor
bolts

: 18 - 24 N·m (1.8 - 2.4 kg-m,
13 - 17 lb-ft)

WPD014
