Nissan March K13. Manual - part 538

PG-140

< BASIC INSPECTION >

BATTERY CHARGING CHART

• Keep battery away from open flame while it is being charged.
• When connecting charger, connect leads first, then turn on charger. Never turn on charger first, as

this may cause a spark.

• If battery temperature rises above 55

°

C (131

°

F), stop charging. Always charge battery when its tem-

perature is below 55

°

C (131

°

F).

Standard Charge

INFOID:0000000005911879

1.

DETERMINE INITIAL CHARGING CURRENT

1.

Determine initial charging current from specific gravity.

2.

Check battery type and determine the specified current using the table.

NOTE:
After starting charging, adjustment of charging current is not necessary.

Initial Charging Current Setting (Standard Charge)

>> GO TO 2.

2.

CHARGE BATTERY

Charge battery for 8 hours.

>> GO TO 3.

3.

CHECKING SPECIFIC GRAVITY

Check specific gravity. Refer to

PG-130, "How to Handle Battery"

.

Is the specific gravity 1.240 or more?

YES

>> Complete standard charge. Perform “CAPACITY TEST”. Refer to

PG-132, "Work Procedure"

.

NO

>> GO TO 4.

4.

CONDUCT ADDITIONAL CHARGE

Add charging time depending on specific gravity.

Additional Charge (Standard Charge)

>> Complete standard charge. Perform “CAPACITY TEST”. Refer to

PG-132, "Work Procedure"

.

CAUTION:

CONVERTED SPECIFIC

GRAVITY

BATTERY TYPE

28

B19

L

/R

34

B19

L

/R

46

B24

L

/R

55

B24

L

/R

50

D23

L

/R

55

D23

L

/R

025 [YUASA type code]

027 [YUASA type code]

80

D23

L

/R

65

D26

L

/R

80

D26

L

/R

067 [YUASA type code]

096 [YUASA type code]

75

D31

L

/R

95

D31

L

/R

1

1

5

D

31

L/R

1

1

0

D

26

L/R

95

E41

L

/R

13

0E4

1

L

/R

1.100 - 1.130

4.0 (A)

5.0 (A)

6.0 (A)

7.0 (A)

8.0
(A)

9.0 (A)

13.0

(A)

1.130 - 1.160

3.0 (A)

4.0 (A)

5.0 (A)

6.0 (A)

7.0
(A)

8.0 (A)

11.0

(A)

1.160 - 1.190

2.0 (A)

3.0 (A)

4.0 (A)

5.0 (A)

6.0
(A)

7.0 (A)

9.0
(A)

1.190 - 1.220

2.0 (A)

2.0 (A)

3.0 (A)

4.0 (A)

5.0
(A)

5.0 (A)

7.0
(A)

SPECIFIC GRAVITY

CHARGING TIME (h)

Below 1.150

3.5

1.150 - 1.200

2.5

1.200 - 1.240

1.5

PG

BATTERY CHARGING CHART

PG-141

< BASIC INSPECTION >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

• Never use standard charge method on a battery whose specific gravity is less than 1.100.
• Set charging current to value specified in “Initial Charging Current Setting (Standard Charge)”. If

charger is not capable of producing specified current value, set its charging current as close to that
value as possible.

• Keep battery away from open flame while it is being charged.
• When connecting charger, connect leads first, then turn on charger. Never turn on charger first, as

this may cause a spark.

• If battery temperature rises above 55

°

C (131

°

F), stop charging. Always charge battery when its tem-

perature is below 55

°

C (131

°

F).

Quick Charge

INFOID:0000000005911880

1.

DETERMINE INITIAL CHARGING CURRENT

1.

Determine initial charging current setting and charging time from specific gravity.

2.

Check battery type and determine the specified current using the table.

NOTE:
After starting charging, adjustment of charging current is not necessary.

Initial Charging Current Setting and Charging Time (Quick Charge)

CAUTION:

• Never use quick charge method on a battery whose specific gravity is less than 1.100.
• Set initial charging current to value specified in “Initial Charging Current Setting and Charging Time

(Quick Charge)”. If charger is not capable of producing specified current value, set its charging cur-
rent as close to that value as possible.

• Keep battery away from open flame while it is being charged.
• When connecting charger, connect leads first, then turn on charger. Never turn on charger first, as

this may cause a spark.

• Be careful of a rise in battery temperature because a large current flow is required during quick-

charge operation.
If battery temperature rises above 55

°

C (131

°

F), stop charging. Always charge battery when its tem-

perature is below 55

°

C (131

°

F).

• Never exceed the charging time specified in “Initial Charging Current Setting and Charging Time

(Quick Charge)”, because charging battery over the charging time can cause deterioration of the
battery.

>> GO TO 2.

2.

CHARGE BATTERY

Charge battery.

BATTERY TYPE

28

B1

9L/

R

34

B1

9L/

R

46

B2

4L/

R

55

B2

4L/

R

50

D2

3L

/R

55

D2

3L

/R

80

D2

3L

/R

65

D2

6L

/R

80

D2

6L

/R

0

2

5

 [YUAS

A

 type

 cod

e

]

0

2

7

 [YUAS

A

 type

 cod

e

]

0

6

7

 [YUAS

A

 type

 cod

e

]

0

9

6

 [YUAS

A

 type

 cod

e

]

75

D3

1L

/R

95

D3

1L

/R

1

1

5D31

L/

R

1

1

0D26

L/

R

95

E4

1L/

R

13

0E4

1

L

/R

CURRENT [A]

10

15

20

25

30

40

C

O

NVER

TED S

PECIFIC

GRA

V

IT

Y

1.100 -

1.130

2.5 hours

1.130 -

1.160

2.0 hours

1.160 -

1.190

1.5 hours

1.190 -

1.220

1.0 hour

Above

1.220

0.75 hour (45 min.)

PG-142

< BASIC INSPECTION >

BATTERY CHARGING CHART

>> Complete quick charge. Perform “CAPACITY TEST”. Refer to

PG-132, "Work Procedure"

.

PG

BATTERY

PG-143

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

REMOVAL AND INSTALLATION

BATTERY

Exploded View

INFOID:0000000005911881

Removal and Installation

INFOID:0000000005911882

REMOVAL

1.

Remove cover of battery positive terminal.

2.

Loosen battery terminal nuts, and disconnect both battery cables from battery terminals.

CAUTION:

When disconnecting, disconnect the battery cable from the negative terminal first.

3.

Remove battery fix frame mounting nuts and battery fix frame.

4.

Remove battery.

INSTALLATION

Install in the reverse order of removal.

CAUTION:

When connecting, connect the battery cable to the positive terminal first.
Reset electronic systems as necessary. Refer to

GI-46, "ADDITIONAL SERVICE WHEN REMOVING BAT-

TERY NEGATIVE TERMINAL : Required Procedure After Battery Disconnection"

.

1

: Battery fix frame

Refer to

GI-3, "Contents"

 for symbols in the figure.

JSMIA0235GB
