MWI-26

< ECU DIAGNOSIS INFORMATION >

COMBINATION METER

*: This harness is not used.

Fail-Safe

INFOID:0000000005883872

FAIL-SAFE

The combination meter activates the fail-safe control if CAN communication with each unit is malfunctioning.

23

(B/W)

Ground

Ground

Ignition
switch
ON

0  V

28

(P)

Ground

Overdrive control switch
signal

Input

Ignition
switch
ON

While pressing the over-
drive control switch.

0 V

Other than the above

12 V

31

(G)

Ground

Security signal

Input

Ignition
switch
ON

Security warning lamp ON

0 V

Security warning lamp OFF

12 V

32

(V)

Ground

Air bag signal

Input

Ignition
switch
ON

Air bag warning lamp
ON

6 V

Air bag warning lamp
OFF

0 V

35

(Y)

Ground

Alternator signal

Input

Ignition
switch
ON

Charge warning lamp ON

2 V

Charge warning lamp OFF

12 V

36

(LG)

Ground

Brake fluid level switch sig-
nal

Input

Ignition
switch
ON

Brake fluid level is normal

12 V

Brake fluid level is less than
low level

0 V

37

(SB)

Ground

Parking brake switch signal

Input

Ignition
switch
ON

Parking brake applied.

0 V

Parking brake released.

12 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

Signal name

Input/

Output

Function

Specifications

Speedometer (A/T models)

Reset to zero by suspending communication.

Tachometer

Illumination control

When suspending communication, changes to nighttime mode.

Information display

Shift position indicator

The indicator turns OFF by suspending communication.

Instantaneous fuel consumption

• When reception time of an abnormal signal is 2 seconds or

less, the last received datum is used for calculation to indi-
cate the result.

• When reception time of an abnormal signal is more than two

seconds, the last result calculated during normal condition is
indicated.

Average fuel consumption

Possible driving distance

Engine start operation indicator

The indicator turns OFF by suspending communication.

Buzzer

The buzzer turns off by suspending communication.

MWI

COMBINATION METER

MWI-27

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

DTC Index

INFOID:0000000005883873

Warning lamp/indicator lamp

ABS warning lamp

The lamp turns ON by suspending communication.

EPS warning lamp

Brake warning lamp (With ABS)

High water temperature warning lamp

The lamp turns OFF by suspending communication.

Malfunction indicator lamp

High beam indicator lamp

Turn signal indicator lamp

Front fog lamp indicator lamp

Door warning lamp

Shift P warning lamp

Key warning lamp

Oil pressure warning lamp

OD OFF indicator lamp

Function

Specifications

Display contents of CONSULT-III

Diagnostic item is detected when...

Refer to

CAN COMM CIRCUIT
[U1000]

When combination meter is not transmitting or receiving CAN communication signal
for 2 seconds or more.

MWI-35,
"Diagnosis
Procedure"

CONTROL UNIT (CAN)
[U1010]

When detecting error during the initial diagnosis of the CAN controller of combina-
tion meter.

XX-XX,
"*****"

VEHICLE SPEED
[B2205]

The abnormal vehicle speed signal is input from the ABS actuator and electric unit
(control unit) for 2 seconds or more.

MWI-37,
"Diagnosis
Procedure"

ENGINE SPEED
[B2267]

If ECM continuously transmits abnormal engine speed signals for 2 seconds or
more.

MWI-38,
"Diagnosis
Procedure"

WATER TEMP
[B2268]

If ECM continuously transmits abnormal engine coolant temperature signals for 60
seconds or more.

MWI-39,
"Diagnosis
Procedure"

MWI-28

< ECU DIAGNOSIS INFORMATION >

IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)

IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE
ROOM)

List of ECU Reference

INFOID:0000000005883874

ECU

Reference

IPDM E/R

With intelligent key models

PCS-15, "Reference Value"

PCS-20, "Fail-Safe"

PCS-45, "DTC Index"

Without intelligent key models

PCS-40, "Reference Value"

PCS-44, "Fail-Safe"

PCS-45, "DTC Index"

MWI

METER SYSTEM

MWI-29

< WIRING DIAGRAM >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

WIRING DIAGRAM

METER SYSTEM

LHD

LHD : Wiring Diagram

INFOID:0000000005883875

For connector terminal arrangements, harness layouts, and alphabets in a

(option abbreviation; if not

described in wiring diagram), refer to

GI-12, "Connector Information"

.

JCNWM3062GB
