ROUTE SEARCHING
NLEL0634S05
Symptom
Cause
Remedy
No route is shown.
No road to be searched is found around the
destination.
Find wider road (orange road or wider)
nearby and reset the destination and pass-
ing points onto it. Take care of the traveling
direction when there are separate up and
down roads.
Starting point and the destination are too close.
Set the destination at more distant point.
Conditional traffic regulation (day of the week/
time of the day) is set at the area around the
current position or the destination.
Turn the time-regulating search conditions
OFF. Turn “Avoid regulation time” in the
search conditions OFF.
Indicated route is intermittent.
In some areas, highways (gray routes) are not
used for the search Therefore, the route to the
current position or the passing points may be
intermittent.
System is not malfunction.
When the vehicle has passed the
recommended route, it is deleted
from the screen.
A recommended route is controlled by each
section. When the vehicle has passed the pass-
ing point 1, then the map data from the starting
point up to the passing point 1 will be deleted.
(The data may remain undeleted in some area.)
System is not malfunction.
Detouring route is recommended.
In some areas, highways (gray routes) are not
used for the search. Therefore, detour route
may be recommended.
Set the route closer to the basic route (gray
route).
A detour route may be shown when some traffic
regulation (one-way traffic, etc.) is set at the
area around the starting point or the destina-
tion.
Slightly move the starting point or the
destination, or set the passing point on the
route of your choice.
In the area where highways (gray routes) are
used for the search, left turn has priority around
the current position and the destination (pass-
ing points). For this reason, the recommended
route may be detouring.
System is not malfunction.
Landmarks on the map do not
match the actual ones.
This can happen due to omission or error in the
map data.
As a rule, an updated map DVD-ROM will
be released once a year. Wait until the lat-
est map has become available.
Recommended route is far from
the starting point, passing points,
and destination.
Starting point, passing points, and destination
of the route guide were set far from the desired
points because route searching data around
these area were not stored.
Reset the destination onto the road nearby.
If this road is one of the highways (gray
routes), an ordinary road nearby may be
displayed as the recommended route.
NAVIGATION SYSTEM
Example of Symptoms Judged Not Malfunction (Cont’d)
