EC-562
[QG (WITHOUT EURO-OBD)]
PRECAUTIONS
●
Do not depress accelerator pedal when starting.
●
Immediately after starting, do not rev up engine unneces-
sarily.
●
Do not rev up engine just prior to shutdown.
●
When installing C.B. ham radio or a mobile phone, be sure
to observe the following as it may adversely affect elec-
tronic control systems depending on installation location.
–
Keep the antenna as far as possible from the electronic
control units.
–
Keep the antenna feeder line more than 20 cm (8 in) away
from the harness of electronic controls.
Do not let them run parallel for a long distance.
–
Adjust the antenna and feeder line so that the standing-
wave radio can be kept smaller.
–
Be sure to ground the radio to vehicle body.
●
Regarding V10 models with A/T, “B1” indicates bank 1 (cyl-
inders number 1 and 4), “B2” indicates bank 2 (cylinders
number 2 and 3).
Wiring Diagrams and Trouble Diagnosis
EBS00QUK
When you read wiring diagrams, refer to the following:
●
“HOW TO READ WIRING DIAGRAMS”, GI-11
●
“POWER SUPPLY ROUTING”, EL-11 for power distribution circuit
When you perform trouble diagnosis, refer to the following:
●
“How to Follow Test Groups in Trouble Diagnoses”, GI-32
●
“HOW TO PERFORM EFFICIENT DIAGNOSES FOR AN ELECTRICAL INCIDENT”, GI-21
SEF709Y
SEF708Y
SEF440Y
