Nissan Almera Tino V10. Manual - part 173
AT-416
[ALL]
REMOVAL AND INSTALLATION
4.
Tighten bolts fixing transaxle.
5.
Reinstall any part removed.
6.
Adjust control cable. Refer to
AT-412, "Control Cable Adjust-
.
7.
Check continuity of PNP switch. Refer to
PARK/NEUTRAL POSITION (PNP) SWITCH"
.
8.
Refill transaxle with ATF and check fluid level.
9.
Move selector lever through all positions to be sure that tran-
saxle operates correctly. With parking brake applied, idle
engine. Move selector lever through “N” to “D”, to “2”, to “1” and
“R” positions. A slight shock should be felt through the hand
gripping the selector each time the transaxle is shifted.
10. Perform road test. Refer to
.
Bolt No.
Tightening torque
N-m (kg-m, ft-lb)
Bolt length “ L ”
mm (in)
1
70 - 79 (7.1 - 8.1, 51 - 59)
55 (2.17)
2
70 - 79 (7.1 - 8.1, 51 - 59)
50 (1.97)
3
70 - 79 (7.1 - 8.1, 51 - 59)
65 (2.56)
4
16 - 21 (1.6 - 2.1, 12 - 15)
35 (1.38)
5
16 - 21 (1.6 - 2.1, 12 - 15)
47 (1.85)
MCIB9009E
SAT638A
