CAN COMMUNICATION
CAN COMMUNICATION UNIT FOR MODELS WITHOUT ESP
System diagram
Input/output signal chart
T: Transmit R: Receive
Steering angle sensor signal
R
T
A/T position indicator signal
R
T
R
R
ABS warning lamp signal
T
R
Slip indicator lamp signal
T
R
VDC Off indicator lamp signal
T
R
Brake warning lamp signal
T
R
N range switch signal
R
T
P range switch signal
R
T
Signals
ECM
TCM
ESP/TCS/
ABS control
unit
Smart
entrance
control unit
Steering
angle sensor
Combination
meter
YEL468E
Signals
ECM
TCM
ABS actuator
and electric
unit (control
unit)
Smart entrance
control unit
Combination
meter
Engine speed signal
T
R
Brake switch signal
R
T
Rear window defogger signal
R
T
Heater fan switch signal
R
T
Air conditioner switch signal
R
T
MI signal
T
R
Engine coolant temperature signal
T
R
Fuel consumption signal
T
R
Vehicle speed signal
T
R
R
T
Seat belt reminder signal
R
T
Headlamp switch signal
T
R
Flashing indicator signal
T
R
Engine cooling fan speed signal
T
R
Door switches state signal
T
R
A/C compressor signal
T
R
A/C compressor feedback signal
T
R
Accelerator pedal position signal
T
R
Output shaft revolution signal
R
T
