Nissan Almera Tino V10. Manual - part 138





AT-276

[EXC.F/EURO-OBD]

TROUBLE DIAGNOSIS — BASIC INSPECTION

14. Touch “DISPLAY”.

15. Touch “PRINT”.

16. Check the monitor data printed out.

17. Continue cruise test part 2 and 3.

Without CONSULT-II

Throttle position sensor can be checked by voltage across termi-
nals 41 and 42 of TCM.

SAT975J

SCIA0710E

TROUBLE DIAGNOSIS — BASIC INSPECTION

AT-277

[EXC.F/EURO-OBD]

D

E

F

G

H

I

J

K

L

M

A

B

AT

Cruise Test — Part 1

1.

CHECK STARTING GEAR (D

1

) POSITION

1.

Drive vehicle for approx. 10 minutes to warm engine oil and ATF up to operating
temperature.

2.

Park vehicle on flat surface.

3.

Set overdrive control switch to “ON” position.

4.

Move selector lever to “P” position.

5.

Start engine.

6.

Move selector lever to “D” position.

7.

Accelerate vehicle by constantly depressing accelerator pedal
halfway.

8.

Does vehicle start from D

1

?

Read gear position.

Yes or No

Yes

>> GO TO 2

No

>>

GO TO

AT-321, "8. Vehicle Cannot Be Started From

D

1

"

.

Continue ROAD TEST. Refer to

AT-268, "Road Test"

.

ATF operating temperature: 50 - 80

°

C (122 - 176

°

F)

SAT774B

SAT775B

SAT495G

AT-278

[EXC.F/EURO-OBD]

TROUBLE DIAGNOSIS — BASIC INSPECTION

2.

CHECK SHIFT UP (D

1

TO D

2

)

Does A/T shift from D

1

to D

2

at the specified speed?

Read gear position, throttle opening and vehicle speed.

Yes or No

Yes

>> GO TO 3

No

>>

GO TO

AT-324, "9. A/T Does Not Shift: D

1

D

2

Or

Does Not Kick down: D

4

D

2

"

.

Continue ROAD TEST. Refer to

AT-268, "Road Test"

.

3.

CHECK SHIFT UP (D

2

TO D

3

)

Does A/T shift from D

2

to D

3

at the specified speed?

Read gear position, throttle position and vehicle speed.

Yes or No

Yes

>> GO TO 4

No

>>

GO TO

AT-326, "10. A/T Does Not Shift: D

2

D

3

"

.

Continue ROAD TEST. Refer to

AT-268, "Road Test"

.

4.

CHECK SHIFT UP (D

3

TO D

4

)

Does A/T shift from D

3

to D

4

at the specified speed?

Read gear position, throttle position and vehicle speed.

Yes or No

Yes

>> GO TO 5

No

>>

GO TO

AT-328, "11. A/T Does Not Shift: D

3

D

4

"

.

Continue ROAD TEST. Refer to

AT-268, "Road Test"

.

Specified speed when shifting from D

1

to D

2

:

Refer to

AT-519, "Shift Schedule"

.

SAT954I

Specified speed when shifting from D

2

to D

3

:

Refer to

AT-519, "Shift Schedule"

.

SAT955I

Specified speed when shifting from D

3

to D

4

:

Refer to

AT-519, "Shift Schedule"

.

SAT956I

TROUBLE DIAGNOSIS — BASIC INSPECTION

AT-279

[EXC.F/EURO-OBD]

D

E

F

G

H

I

J

K

L

M

A

B

AT

5.

CHECK LOCK-UP (D

4

TO D

4

L/U)

Does A/T perform lock-up at the specified speed?

Read vehicle speed, throttle position when lock-up duty becomes 94%.

Yes or No

Yes

>> GO TO 6

No

>>

GO TO

AT-330, "12. A/T Does Not Perform Lock-up"

.

Continue ROAD TEST. Refer to

AT-268, "Road Test"

.

6.

CHECK HOLD LOCK-UP

Does A/T hold lock-up condition for more than 30 seconds?

Yes or No

Yes

>> GO TO 7

No

>>

GO TO

AT-330, "13. A/T Does Not Hold Lock-up Condition"

.

Continue ROAD TEST. Refer to

AT-268, "Road Test"

.

7.

CHECK SHIFT DOWN (D

4

L/U TO D

4

)

1.

Release accelerator pedal.

2.

Is lock-up released when accelerator pedal is released?

Yes or No

Yes

>> GO TO 8

No

>>

GO TO

AT-332, "14. Lock-up Is Not Released"

.

Continue ROAD TEST. Refer to

AT-268, "Road Test"

.

8.

CHECK SHIFT DOWN (D

4

TO D

3

)

1.

Decelerate vehicle by applying foot brake lightly.

2.

Does engine speed return to idle smoothly when A/T is shifted from D

4

to D

3

?

Read gear position and engine speed.

Yes or No

Yes

>> 1. Stop vehicle.

2. GO TO

AT-280, "Cruise Test — Part 2"

.

No

>>

GO TO

AT-332, "15. Engine Speed Does Not Return

To Idle (Light Braking D

4

D

3

)"

.

Continue ROAD TEST. Refer to

AT-268, "Road Test"

.

Specified speed when lock-up occurs:

Refer to

AT-519, "Shift Schedule"

.

SAT957I

SAT958I

SAT959I
