ENGINE OIL

LU-7

< PERIODIC MAINTENANCE >

C

D

E

F

G

H

I

J

K

L

M

A

LU

N

P

O

4.

Stop the engine and wait for 5 minutes.

5.

Check the engine oil level. Refer to

LU-4, "Inspection"

.

LU-8

< PERIODIC MAINTENANCE >

OIL FILTER

OIL FILTER

Removal and Installation

INFOID:0000000009164371

REMOVAL

CAUTION:

• Oil filter is provided with relief valve. Use genuine NISSAN oil filter or equivalent.
• Be careful not to get burned when engine and engine oil may be hot.
• When removing, prepare a shop cloth to absorb any engine oil leakage or spillage.
• Never allow engine oil to adhere to drive belt.
• Completely wipe off any engine oil that adheres to engine and vehicle.

1.

Remove front undercover. Refer to

EXT-37, "FRONT UNDER COVER : Exploded View"

.

2.

Using oil filter wrench [SST: KV10115801 (J-38956)] (A), remove
oil filter.

INSTALLATION

1.

Remove foreign materials adhering to oil filter installation surface.

2.

Apply engine oil to the oil seal contact surface of new oil filter.

3.

Screw oil filter manually until it touches the installation surface,
then tighten it by 2/3 turn (A). Or tighten to the specification.

Inspection

INFOID:0000000009164372

INSPECTION AFTER INSTALLATION

1.

Check the engine oil level. Refer to

LU-4, "Inspection"

.

2.

Start the engine, and check there is no leakage of engine oil.

3.

Stop the engine and wait for 5 minutes.

4.

Check the engine oil level, and adjust the level. Refer to

LU-4, "Inspection"

.

: Vehicle front

NNBIA0116ZZ

SMA010

Oil filter:

: 17.7 N·m (1.8 kg-m, 13 ft-lb)

JPBIA0077ZZ

SERVICE DATA AND SPECIFICATIONS (SDS)

LU-9

< SERVICE DATA AND SPECIFICATIONS (SDS)

C

D

E

F

G

H

I

J

K

L

M

A

LU

N

P

O

SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)

Periodical Maintenance Specification

INFOID:0000000009161736

ENGINE OIL CAPACITY (APPROXIMATELY)

Unit:

 (US qt, lmp qt)

Drain and refill

With oil filter change

5.0 (5-1/4, 4-3/8)

Without oil filter change

4.5 (4-3/4, 4)

Dry engine (Overhaul)

6.2 (6-4/8, 5-4/8)

MA-1

MAINTENANCE

C

D

E

F

G

H

I

J

K

L

M

B

MA

SECTION

MA

N

O

A

CONTENTS

MAINTENANCE

PREPARATION ............................................

3

PREPARATION ...................................................

3

Special Service Tool  .................................................

3

Commercial Service Tool  ..........................................

3

FEATURES OF NEW MODEL ......................

4

ABOUT GT-R MAINTENANCE  ...........................

4

Description ................................................................

4

GT-R Special Specification Parts ..............................

4

PERIODIC MAINTENANCE ..........................

8

GENERAL MAINTENANCE  ................................

8

Explanation of General Maintenance  ........................

8

PERFORMANCE OPTIMIZATION SERVICES

....

10

Explanation of Performance Optimization Servic-
es ............................................................................

10

Sample of GT-R Performance Optimization Ser-
vice Log ...................................................................

11

PERIODIC MAINTENANCE  ...............................

12

Introduction of Periodic Maintenance ......................

12

Schedule 1  ..............................................................

12

Schedule 2  ..............................................................

13

ADDITIONAL MAINTENANCE ITEMS  ..............

16

Description ..............................................................

16

Precautions on Performance Driving  ......................

16

Inspection and Adjustments before Performance
Driving .....................................................................

17

Inspection and Adjustments after Performance
Driving .....................................................................

19

RECOMMENDED FLUIDS AND LUBRI-
CANTS ................................................................

22

Fluids and Lubricants  ..............................................

22

Engine Oil Recommendation  ..................................

22

Anti-Freeze Coolant Mixture Ratio  ..........................

22

ENGINE MAINTENANCE .................................

24

DRIVE BELT  ..............................................................

24

DRIVE BELT : Exploded View .................................

24

DRIVE BELT : Checking ..........................................

24

DRIVE BELT : Tension Adjustment (GT-R certi-
fied NISSAN dealer)  ................................................

24

ENGINE COOLANT  ...................................................

24

ENGINE COOLANT : Inspection  .............................

24

ENGINE COOLANT : Draining  ................................

25

ENGINE COOLANT : Refilling .................................

26

ENGINE COOLANT : Flushing ................................

27

AIR CLEANER FILTER  .............................................

27

AIR CLEANER FILTER : Removal and Installation

....

27

ENGINE OIL ...............................................................

28

ENGINE OIL : Draining ............................................

28

ENGINE OIL : Refilling  ............................................

28

OIL FILTER  ................................................................

29

OIL FILTER : Removal and Installation  ...................

29

OIL FILTER : Inspection  ..........................................

30

SPARK PLUG  ............................................................

30

SPARK PLUG : Removal and Installation  ...............

30

SPARK PLUG : Inspection  ......................................

30

THROTTLE CHAMBER  .............................................

31

THROTTLE CHAMBER : Inspection  .......................

31

EVAP VAPOR LINES  ................................................

31

EVAP VAPOR LINES : Inspection ...........................

31

CHASSIS MAINTENANCE  ...............................

32

TRANSMISSION OIL  .................................................

32

TRANSMISSION OIL : Inspection  ...........................

32

TRANSMISSION OIL : Draining  ..............................

34

TRANSMISSION OIL : Filling  ..................................

35

TRANSFER FLUID  ....................................................

36
