LAN-16

< DTC/CIRCUIT DIAGNOSIS >

[CAN]

CAN COMMUNICATION SYSTEM

Wiring Diagram - CAN SYSTEM -

INFOID:0000000009163500

For connector terminal arrangements, harness layouts, and alphabets in a

(option abbreviation; if not

described in wiring diagram), refer to

GI-12, "Connector Information"

.

JRMWD5789GB

LAN

CAN COMMUNICATION SYSTEM

LAN-17

< DTC/CIRCUIT DIAGNOSIS >

[CAN]

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

JRMWD5790GB

LU-1

ENGINE

C

D

E

F

G

H

I

J

K

L

M

SECTION

LU

A

LU

N

O

P

CONTENTS

ENGINE LUBRICATION SYSTEM

PRECAUTION ...............................................

2

PRECAUTIONS ...................................................

2

Precaution for Working Range at a Regular Deal-
ership ........................................................................

2

Precaution for Battery Service  ..................................

2

General Precautions  .................................................

2

Liquid Gasket ...........................................................

2

PREPARATION ............................................

3

PREPARATION ...................................................

3

Special Service Tools ..............................................

3

PERIODIC MAINTENANCE ..........................

4

ENGINE OIL  .......................................................

4

Inspection .................................................................

4

Draining ....................................................................

6

Refilling .....................................................................

6

OIL FILTER  ........................................................

8

Removal and Installation  ..........................................

8

Inspection .................................................................

8

SERVICE DATA AND SPECIFICATIONS
(SDS) .............................................................

9

SERVICE DATA AND SPECIFICATIONS
(SDS) ..................................................................

9

Periodical Maintenance Specification .....................

9

LU-2

< PRECAUTION >

PRECAUTIONS

PRECAUTION

PRECAUTIONS

Precaution for Working Range at a Regular Dealership

INFOID:0000000009164367

CAUTION:

The service items unmentioned on this manual are recommended to be performed by a GT-R certified
NISSAN dealer. Because those service items require special equipment and a GT-R certified technical
staff who completed special training.

Precaution for Battery Service

INFOID:0000000009161716

Before disconnecting the battery, lower both the driver and passenger windows. This will prevent any interfer-
ence between the window edge and the vehicle when the door is opened/closed. During normal operation, the
window slightly raises and lowers automatically to prevent any window to vehicle interference. The automatic
window function will not work with the battery disconnected.

General Precautions

INFOID:0000000009161717

CAUTION:

After finishing servicing, check that all the tools and waste are stored in a customary place.

Liquid Gasket

INFOID:0000000009161719

LIQUID GASKET APPLICATION PROCEDURE

1.

Remove old liquid gasket adhering to the liquid gasket application surface and the mating surface.
• Remove liquid gasket completely from the liquid gasket application surface, mounting bolts, and bolt

holes.

2.

Wipe the liquid gasket application surface and the mating surface with white gasoline (lighting and heating
use) to remove adhering moisture, grease and foreign materials.

3.

Apply liquid gasket to the liquid gasket application surface.
Use Genuine RTV Silicone Sealant or equivalent. Refer to

GI-18, "Recommended Chemical Prod-

ucts and Sealants"

.

• Within five minutes of liquid gasket application, install the mating component.
• If liquid gasket protrudes, wipe it off immediately.
• Do not retighten mounting bolts or nuts after the installation.
• After 30 minutes or more have passed from the installation, fill engine oil and engine coolant.
