TRANSFER ASSEMBLY DLN-181 < DISASSEMBLY AND ASSEMBLY > [TRANSFER: ATX14B] C E F G H I J K L M A B DLN N O P 38. Install the main oil pump cover to the center case, and tighten to the specified torque. Refer to 39. Remove all the sealant from the switch location area and inside the center case. CAUTION: Remove old sealant adhering to mounting surfaces. Also remove any moisture, oil, or foreign material adhering to application and mounting surfaces. 40. Thread the ATP switch and neutral-4LO switch in one to two pitches and apply sealant to the threads of the switches. Tighten to the specified torque. Refer to • Use Genuine Silicone RTV or equivalent. Refer to "Recommended Chemical Products and Sealants" . NOTE: • Neutral-4LO switch harness connector is gray. • ATP switch harness connector is black. 41. Install the front drive shaft rear bearing using Tools. 42. Install the front drive shaft to the front bearing using Tools. SDIA2130E Tool number A: KV40100621 (J-25273) SDIA3435E SDIA2198E Tool number A: KV40100621 (J-25273) SDIA2199E 2010 Pathfinder |
