DLN-146 < ON-VEHICLE REPAIR > [TRANSFER: ATX14B] AIR BREATHER HOSE • Install each air breather hose into the breather tube (4). Set each air breather hose with paint mark facing upward. - A: Paint marks • Install actuator/transfer motor air breather hose (1) and trans- fer air breather hose (2) on clip (A) with the paint mark (B) fac- : Front • Install clip (A) on actuator/transfer motor air breather hose (1) and transfer air breather hose (2) with the paint mark (B) : Front • Install actuator/transfer motor air breather hose (1) and trans- fer air breather hose (2) on clip (C) and clip (B) with the paint : Front ALDIA0110ZZ ALDIA0111ZZ AWDIA0011ZZ AWDIA0012ZZ 2009 Pathfinder |
