PRECAUTIONS

LAN-43

[CAN]

C

D

E

F

G

H

I

J

L

M

A

B

LAN

2007 Pathfinder

●

Bypass connection is never allowed at the repaired area.

NOTE:
Bypass connection may cause CAN communication error. The
spliced wire becomes separated and the characteristics of
twisted line are lost.

●

Replace the applicable harness as an assembly if error is detected on the shield lines of CAN communi-
cation line.

SKIB8767E

LAN-44

[CAN]

TROUBLE DIAGNOSIS

2007 Pathfinder

TROUBLE DIAGNOSIS

PFP:00004

CAN Diagnostic Support Monitor

UKS006HM

Use “CAN DIAG SUPPORT MNTR” for detecting the root cause.

MONITOR ITEM LIST (CONSULT-II)
ECM

0: Error at present, 1 – 39: Error in the past (Number means the number of times the ignition switch is turned OFF

→

ON)

*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.

TCM

NOTE:
Replace the unit when “NG” is indicated on the “INITIAL DIAG”.

SELECT SYS-

TEM

CAN DIAG SUP-

PORT MNTR

Description

Normal

Error

PRSNT

PAST

PRSNT

PAST

ENGINE

TRANSMIT DIAG

Signal transmission status

OK

OK

or

1 – 39

*

UNKWN

0

VDC/TCS/ABS

Signal receiving status from the ABS actu-
ator and electric unit (control unit)

METER/M&A

Signal receiving status from the combina-
tion meter

BCM/SEC

Signal receiving status from the BCM

ICC

Not used even though indicated

HVAC

TCM

Signal receiving status from the TCM

OK

OK

or

1 – 39

*

UNKWN

0

EPS

Not used even though indicated

IPDM E/R

Signal receiving status from the IPDM E/R

OK

OK

or

1 – 39

*

UNKWN

0

e4WD

Not used even though indicated

AWD/4WD

Signal receiving status from the transfer
control unit

OK

OK

or

1 – 39

*

UNKWN

0

SELECT SYS-

TEM

CAN DIAG SUP-

PORT MNTR

Description

Normal

Error

PRSNT

A/T

INITIAL DIAG

Status of CAN controller

OK

NG

TRANSMIT DIAG

Signal transmission status

UNKWN

ECM

Signal receiving status from the ECM

VDC/TCS/ABS

Signal receiving status from the ABS actuator and electric unit
(control unit)

METER/M&A

Signal receiving status from the combination meter

ICC/e4WD

Not used even though indicated

AWD/4WD

Signal receiving status from the transfer control unit

OK

UNKWN

TROUBLE DIAGNOSIS

LAN-45

[CAN]

C

D

E

F

G

H

I

J

L

M

A

B

LAN

2007 Pathfinder

Transfer Control Unit (Part Time 4WD Models)

NOTE:
Replace the unit when “NG” is indicated on the “INITIAL DIAG”.

Transfer Control Unit (All-mode 4WD Models)

0: Error at present, 1 – 39: Error in the past (Number means the number of times the ignition switch is turned OFF

→

ON)

*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.

Driver Seat Control Unit

0: Error at present, 1 – 39: Error in the past (Number means the number of times the ignition switch is turned OFF

→

ON)

*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.

SELECT SYS-

TEM

CAN DIAG SUP-

PORT MNTR

Description

Normal

Error

PRSNT

ALL MODE AWD/
4WD

INITIAL DIAG

Status of CAN controller

OK

NG

TRANSMIT DIAG

Signal transmission status

UNKWN

ECM

Signal receiving status from the ECM

VDC/TCS/ABS

Signal receiving status from the ABS actuator and electric unit
(control unit)

TCM

Signal receiving status from the TCM

METER/M&A

Signal receiving status from the combination meter

SELECT SYS-

TEM

CAN DIAG SUP-

PORT MNTR

Description

Normal

Error

PRSNT

PAST

PRSNT

PAST

ALL MODE AWD/
4WD

TRANSMIT DIAG

Signal transmission status

OK

OK

or

1 – 39

*

UNKWN

0

ECM

Signal receiving status from the ECM

VDC/TCS/ABS

Signal receiving status from the ABS actu-
ator and electric unit (control unit)

TCM

Signal receiving status from the TCM

STRG

Signal receiving status from the steering
angle sensor

SELECT SYS-

TEM

CAN DIAG SUP-

PORT MNTR

Description

Normal

Error

PRSNT

PAST

PRSNT

PAST

AUTO DRIVE
POS.

TRANSMIT DIAG

Not used even though indicated

METER/M&A

Signal receiving status from the combina-
tion meter

OK

OK

or

1 – 39

*

UNKWN

0

BCM/SEC

Signal receiving status from the BCM

TCM

Signal receiving status from the TCM

LAN-46

[CAN]

TROUBLE DIAGNOSIS

2007 Pathfinder

BCM

NOTE:
Replace the unit when “NG” is indicated on the “INITIAL DIAG”.

Combination Meter

0: Error at present, 1 – 39: Error in the past (Number means the number of times the ignition switch is turned OFF

→

ON)

*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.

ABS Actuator and Electric Unit (Control Unit)

CAUTION:

Never replace the unit even when “NG” is indicated on the “INITIAL DIAG” at this stage. Follow the trouble diagnosis proce-
dures.

SELECT SYS-

TEM

CAN DIAG SUP-

PORT MNTR

Description

Normal

Error

PRSNT

BCM

INITIAL DIAG

Status of CAN controller

OK

NG

TRANSMIT DIAG

Signal transmission status

UNKWN

ECM

Signal receiving status from the ECM

IPDM E/R

Signal receiving status from the IPDM E/R

METER/M&A

Signal receiving status from the combination meter

I-KEY

Not used even though indicated

SELECT SYS-

TEM

CAN DIAG SUP-

PORT MNTR

Description

Normal

Error

PRSNT

PAST

PRSNT

PAST

METER

TRANSMIT DIAG

Signal transmission status

OK

OK

or

1 – 39

*

UNKWN

0

ECM

Signal receiving status from the ECM

TCM

Signal receiving status from the TCM

BCM/SEC

Signal receiving status from the BCM

VDC/TCS/ABS

Signal receiving status from the ABS actu-
ator and electric unit (control unit)

IPDM E/R

Signal receiving status from the IPDM E/R

I-KEY

Not used even though indicated

EPS

AWD/4WD

e4WD

ICC

LANE KEEP

TIRE-P

SELECT SYS-

TEM

CAN DIAG SUP-

PORT MNTR

Description

Normal

Error

PRSNT

ABS

INITIAL DIAG

Status of CAN controller

OK

NG

Caution

TRANSMIT DIAG

Signal transmission status

UNKWN

ECM

Signal receiving status from the ECM

TCM

Signal receiving status from the TCM

METER/M&A

Not used even though indicated

STRG

Signal receiving status from the steering angle sensor

OK

UNKWN

ICC

Not used even though indicated

AWD/4WD

Signal receiving status from the transfer control unit

OK

UNKWN

TROUBLE DIAGNOSIS

LAN-47

[CAN]

C

D

E

F

G

H

I

J

L

M

A

B

LAN

2007 Pathfinder

IPDM E/R

0: Error at present, 1 – 39: Error in the past (Number means the number of times the ignition switch is turned OFF

→

ON)

*: 39 or higher number is fixed at 39 until the self-diagnosis result is erased.

SELECT SYS-

TEM

CAN DIAG SUP-

PORT MNTR

Description

Normal

Error

PRSNT

PAST

PRSNT

PAST

IPDM E/R

TRANSMIT DIAG

Signal transmission status

OK

OK

or

1 – 39

*

UNKWN

0

ECM

Signal receiving status from the ECM

BCM/SEC

Signal receiving status from the BCM

LAN-48

[CAN]

TROUBLE DIAGNOSIS

2007 Pathfinder

MONITOR ITEM LIST (ON-BOARD DIAGNOSIS)
Display Control Unit

NOTE:
CAN diagnostic support monitor of the display control unit is indicated on the vehicle display. Refer to

AV-104,

"Self-Diagnosis Mode (DCU)"

 .

*: The error counter stops counting when it reaches “50” and holds “50” until it is deleted.

PKIC6981E

Unit name

Diagnosis item

Description

Indicated items on CAN DIAG SUPPORT MONITOR

Normal

Error

Result indi-

cated

Error

counter

(Reference)

Result indi-

cated

Error

counter

(Reference)

Display control
unit

CAN_COMM

Status of CAN controller

OK

0

or

1 – 50

*

NG

1 – 50

*

CAN_CIRC_1

Signal transmission status

UNKWN

CAN_CIRC_2

Signal receiving status from the
BCM

CAN_CIRC_3

Signal receiving status from the
ECM

CAN_CIRC_4

Signal receiving status from the
front air control

CAN_CIRC_5

Signal receiving status from the
combination meter

CAN_CIRC_6

Not used even though indicated

CAN_CIRC_7

Signal receiving status from the
IPDM E/R

OK

0

or

1 – 50

*

UNKWN

1 – 50

*

CAN_CIRC_8

Not used even though indicated

CAN_CIRC_9

TROUBLE DIAGNOSIS

LAN-49

[CAN]

C

D

E

F

G

H

I

J

L

M

A

B

LAN

2007 Pathfinder

CAN System Specification Chart

UKS006HN

Determine CAN system type from the following specification chart. Then choose the correct diagnosis sheet.

NOTE:
Refer to

LAN-19, "CHECK OF CAN SYSTEM TYPE (HOW TO USE CAN SYSTEM TYPE SPECIFICATION

CHART)"

  for how to use CAN system specification chart.

×

: Applicable

VEHICLE EQUIPMENT IDENTIFICATION INFORMATION

NOTE:
Check CAN system type from the vehicle shape and equipment.

Body type

Wagon

Axle

2WD

4WD(Part time)

4WD(All-mode)

Engine

VQ40DE

Transmission

A/T

Brake control

VDC

Automatic drive positioner

×

×

×

×

Navigation system

×

×

Automatic air conditioner

×

×

×

×

×

×

×

CAN  system  type

1

2

3

4

5

6

7

8

9

10

Diagnosis sheet

LAN-64

LAN-65

LAN-66

LAN-67

LAN-68

LAN-69

LAN-70

LAN-71

LAN-72

LAN-73

CAN communication signal
chart

LAN-50, "TYPE 1/TYPE 2/TYPE 3/

TYPE 4"

LAN-51, "TYPE 5/

TYPE 6"

LAN-53, "TYPE 7/TYPE 8/TYPE 9/

TYPE10"

BKIA0220E

LAN-50

[CAN]

TROUBLE DIAGNOSIS

2007 Pathfinder

CAN Communication Signal Chart

UKS006HO

Refer to

LAN-15, "How to Use CAN Communication Signal Chart"

  for how to use CAN communication signal

chart.

TYPE 1/TYPE 2/TYPE 3/TYPE 4

NOTE:
Refer to

LAN-41, "Abbreviation List"

  for the abbreviations of the connecting units.

T: Transmit

R: Receive

Signal name/Connecting unit

EC

M

TC

M

ADP

*1

BC

M

HV

AC

*2

M&

A

ST

RG

DI

SP

*3

AB

S

IP

D

M

-E

A/C compressor request signal

T

R

Accelerator pedal position signal

T

R

R

ASCD CRUISE lamp signal

T

R

ASCD OD cancel request

T

R

ASCD operation signal

T

R

ASCD SET lamp signal

T

R

Battery voltage signal

T

R

Closed throttle position signal

T

R

Cooling fan speed request signal

T

R

Engine coolant temperature signal

T

R

R

Engine speed signal

T

R

R

R

R

R

Engine status signal

T

R

Fuel consumption monitor signal

T

R

T

R

Malfunction indicator lamp signal

T

R

Power generation command value signal

T

R

Wide open throttle position signal

T

R

A/T fluid temperature sensor signal

T

R

A/T position indicator lamp signal

T

R

A/T self-diagnosis signal

R

T

O/D OFF indicator signal

T

R

Output shaft revolution signal

R

T

P range signal

T

R

R

R

Turbine revolution signal

R

T

System setting signal

R

R

T

T

T

R

A/C switch signal

R

T

R

Blower fan motor switch signal

R

T

Buzzer output signal

T

R

Day time running light request signal

T

R

R

Door switch signal

R

T

R

R

R

Front fog light request signal

T

R

R

Front wiper request signal

T

R

High beam request signal

T

R

R

Horn chirp signal

T

R

Ignition switch signal

R

T
