HARNESS
PG-61
C
D
E
F
G
H
I
J
L
M
A
B
PG
2006 Pathfinder
D5
B104
W/2
: To E51
A2
B105
W/6
: Rear combination lamp RH
C4
B106
W/12
: To D301
C4
B108
W/3
: Front door switch RH
D4
B110
W/3
: Seat belt buckle switch RH
D3
B113
Y/12
: Air bag diagnosis sensor unit
C5
B114
Y/2
: RH side air bag (satellite) sensor
B3
B116
W/3
: Rear door switch RH
D4
B117
—
: Body ground
C4
B126
Y/2
: Front RH side air bag module
C4
B127
Y/2
: Front RH seat belt pre-tensioner
B2
B128
Y/2
: RH side rear curtain air bag module
D5
B131
W/2
: To M162
A2
B132
—
: Body ground
A2
B133
W/4
: Rear blower motor resistor
D5
†B136
W/16
: To P151 (with power seat)
D4
††B136
W/8
: To P151 (without power seat)
C5
B137
B/3
: Belt tension sensor
A2
B138
B/2
: Rear cargo power socket
D4
B142
W/4
: To M83
E5
B149
SMJ
: To M36
C5
B151
W/40
: NAVI control unit (with NAVI)
C3
B152
W/32
: NAVI control unit (with NAVI)
B3
B155
B/6
: Air mix door motor (rear)
D4
B157
Y/2
: To B78
A3
B175
W/2
: To B200
Rear blower motor sub-harness
A3
B200
W/2
: To B175
A3
B201
B/2
: Rear blower motor
