REMOVAL AND INSTALLATION

WT-31

C

D

F

G

H

I

J

K

L

M

A

B

WT

2005 Pathfinder

3.

Place wheel on turntable of tire machine. Ensure that transmitter
is 270 degrees from mounting/dismounting head.

NOTE:
Do not touch transmitter with mounting head.

4.

Lubricate tire well, and install second side of tire as normal.
Ensure that tire does not rotate relative to rim.

5.

Inflate tire and balance the wheel and tire assembly. Refer to

WT-5, "Wheel Balance Adjustment"

.

6.

Install wheel and tire assembly in appropriate wheel position on
vehicle.

7.

Adjust neutral position of steering angle sensor. Refer to

BRC-

57, "Adjustment of Steering Angle Sensor Neutral Position"

.

SEIA0048E

WT-32

SERVICE DATA AND SPECIFICATIONS (SDS)

2005 Pathfinder

SERVICE DATA AND SPECIFICATIONS (SDS)

PFP:00030

Road Wheel

EES001BZ

Tire

EES001C0

Unit: kPa (kg/cm

2

, psi)

Wheel type

Aluminum

Steel

Inside

Outside

Maximum radial
runout limit

Lateral mm (in)

0.3 (0.012) or less

1.0 (0.039) or less

0.9 (0.035) or less

Radial mm (in)

0.3 (0.012) or less

0.8 (0.031) or less

0.4 (0.016) or less

Maximum residual
imbalance

Dynamic
(at rim flange)

Less than 5 g (0.18 oz) (per side)

Static (at rim flange)

Less than 10 g (0.35 oz)

Tire size

Air pressure

Conventional tire

Spare tire

Full size spare tire

240 (2.4, 35)

P245/75R16

240 (2.4, 35)

P265/70R16

240 (2.4, 35)

P265/75R16

240 (2.4, 35)

P265/65R17

240 (2.4, 35)
