KNUCKLE

FSU-17

C

D

F

G

H

I

J

K

L

M

A

B

FSU

2005 Pathfinder

INSTALLATION

Installation is in the reverse order of removal.

Refer to

FSU-5, "Components"

for tightening torques.

CAUTION:

Always replace drive shaft lock nut and cotter pin.

When installing disc rotor on wheel hub and bearing assembly,
align the marks.

NOTE:
When not using the alignment mark, refer to

BR-36, "Front Disc

Brake"

.

When installing wheel and tire, refer to

WT-6, "Rotation"

.

Perform wheel alignment. Refer to

FSU-6, "Front Wheel Align-

ment"

.

WDIA0044E

FSU-18

SERVICE DATA AND SPECIFICATIONS (SDS)

2005 Pathfinder

SERVICE DATA AND SPECIFICATIONS (SDS)

PFP:00030

General Specifications (Front)

EES001A0

Wheel Alignment (Unladen*

1

)

EES001A1

*1: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.
*2: Target value 35

°

26

(35.43

°

)

*3: Target value 31

°

22

(31.37

°

)

*4: Target value 35

°

33

(35.55

°

)

*5: Target value 31

°

38

(31.63

°

)

Suspension type

Independent double wishbone coil over shock

Shock absorber type

Double-acting hydraulic

Stabilizer

Standard equipment

Drive type

4x2

4x4

Camber
Degree minute (decimal degree)

Minimum

-0

°

15

(-0.25

°

)

0

°

0

(0.00

°

)

Nominal

0

°

15

(0.25

°

)

0

°

30

(0.50

°

)

Maximum

0

°

45

(0.75

°

)

1

°

00

(1.00

°

)

Cross camber

0

°

45

(0.75

°

) or less

0

°

45

(0.75

°

) or less

Caster
Degree minute (decimal degree)

Minimum

2

°

30

(2.50

°

)

2

°

15

(2.25

°

)

Nominal

3

°

0

(3.00

°

)

2

°

45

(2.75

°

)

Maximum

3

°

30

(3.50

°

)

3

°

15

(3.25)

Cross caster

0

°

45

(0.75

°

) or less

0

°

45

(0.75

°

) or less

Kingpin inclination
Degree minute (decimal degree)

Nominal

13

°

0

(13.00

°

)

12

°

45

(12.75

°

)

Total toe-in

Distance (A

B)

Minimum

2.1 mm (0.08 in)

2.1 mm (0.08 in)

Nominal

3.1 mm (0.12 in)

3.1 mm (0.12 in)

Maximum

4.1 mm (0.16 in)

4.1 mm (0.16 in)

Angle (left wheel or right wheel)
Degree minute (decimal degree)

Minimum

0

°

5

(0.08

°

)

0

°

5

(0.08

°

)

Nominal

0

°

7

(0.12

°

)

0

°

7

(0.12

°

)

Maximum

0

°

9

(0.15

°

)

0

°

9

(0.15

°

)

Wheel turning angle (full turn)

Inside
Degree minute (Decimal degree)

33

°

26

– 35

°

26

*

2

(33.43

°

– 35.43

°

)

33

°

33

– 35

°

33

*

4

(33.60

°

– 35.60

°

)

Outside
Degree minute (Decimal degree)

29

°

22

– 31

°

22

*

3

(29.37

°

– 31.37

°

)

29

°

38

– 31

°

38

*

5

(29.73

°

– 31.73

°

)

SFA234AC

SERVICE DATA AND SPECIFICATIONS (SDS)

FSU-19

C

D

F

G

H

I

J

K

L

M

A

B

FSU

2005 Pathfinder

Ball Joint

EES001A2

Wheelarch Height (Unladen*

1

)

EES001PZ

Unit: mm (in)

*1: Fuel, radiator coolant and engine oil full. Spare tire, jack, hand tools and mats in designated positions.

Swinging force “A” (Measurement point at either cotter pin
hole or groove of ball stud.)

Upper

8.1 - 79 N (0.83 - 8.1 kg-f, 1.82 - 17.8 lb-f) at hole

Lower

11.4 - 145.5 N (1.16 - 14.84 kg-f, 2.56 - 32.71 lb-f) at groove

Turning torque “B”

Upper

0.5 - 4.9 N·m (0.05 - 0.49 kg-m, 5 - 43 in-lb)

Lower

0.5 - 6.4 N·m (0.05 - 0.65 kg-m, 5 - 56 in-lb)

Vertical end play “C”

0 mm (0 in)

SFA858A

Drive type

4X2

Part time 4X4

Full time

4X4

Applied model

XE

SE

LE

XE

SE

LE

Tire size

245/75R16

265/70R16

265/75R16

265/65R17

245/75R16

265/70R16

265/75R16

265/65R17

Front wheelarch
height (Hf)

866

(34.09)

867

(34.13)

879

(34.61)

868

(34.17)

874

(34.41)

876

(34.49)

888

(34.96)

878

(34.57)

Rear wheelarch
height (Hr)

875

(34.45)

876

(34.49)

888

(34.96)

877

(34.53)

885

(34.84)

886

(34.88)

898

(35.35)

887

(34.92)

LEIA0085E

FSU-20

SERVICE DATA AND SPECIFICATIONS (SDS)

2005 Pathfinder

-2

This manual contains maintenance and repair procedures for the
2005 NISSAN PATHFINDER.

In order to assure your safety and the efficient functioning of the vehicle,
this manual should be read thoroughly. It is especially important that the
PRECAUTIONS in the GI section be completely understood before starting
any repair task.

All information in this manual is based on the latest product information
at the time of publication. The right is reserved to make changes in specifi-
cations and methods at any time without notice.

IMPORTANT SAFETY NOTICE

The proper performance of service is essential for both the safety of
the technician and the efficient functioning of the vehicle.
The service methods in this Service Manual are described in such a
manner that the service may be performed safely and accurately.
Service varies with the procedures used, the skills of the technician
and the tools and parts available. Accordingly, anyone using service
procedures, tools or parts which are not specifically recommended
by NISSAN must first be completely satisfied that neither personal
safety nor the vehicle’s safety will be jeopardized by the service
method selected.

PLEASE HELP MAKE THIS SERVICE MANUAL BETTER!

Your comments are important to NISSAN and will help us to improve our Service Manuals.
Use this form to report any issues or comments you may have regarding our Service Manuals.
Please print this form and type or write your comments below. Mail or fax to:

Nissan North America, Inc.
Technical Service Information
39001 Sunrise Drive, P.O. Box 9200
Farmington Hills, MI USA 48331
FAX: (248) 488-3910

SERVICE MANUAL: Model:

Year:

PUBLICATION NO. (Please photocopy back cover):
VEHICLE INFORMATION VIN:

Production Date:

Please describe any issues or problems in detail:
Page number(s)

Note: Please include a copy of each page, marked with your comments.

Are the trouble diagnosis procedures logical and easy to use? (circle your answer)

YES

NO

If no, what page number(s)?

Note: Please include a copy of each page, marked with your comments.

Please describe the issue or problem in detail:

Is the organization of the manual clear and easy to follow? (circle your answer)

YES

NO

Please comment:

What information should be included in NISSAN Service Manuals to better support you in servicing or
repairing customer vehicles?

DATE:

YOUR NAME:

POSITION:

DEALER:

DEALER NO.:

ADDRESS:

CITY:

STATE/PROV./COUNTRY:

ZIP/POSTAL CODE:

QUICK REFERENCE CHART PATHFINDER

2005

QUICK REFERENCE CHART PATHFINDER

PFP:00000

Engine Tune-Up Data

ELS000YK

Cylinder arrangement

V-6

Displacement

cm

3

(cu in)

3,954 (241.30)

Bore and stroke

mm (in)

95.5

×

92.0 (3.76

×

3.622)

Valve arrangement

DOHC

Firing order

1-2-3-4-5-6

Number of piston rings

Compression

2

Oil

1

Number of main bearings

4

Compression ratio

9.7

Compression pressure

kPa (kg/cm

2

, psi)/300 rpm

Standard

1,275 (13.0, 185)

Minimum

981 (10.0, 142)

Differential limit between cylinders

98 (1.0, 14)

Cylinder number

Valve timing
(Intake valve timing control - “OFF”)

Unit: degree

a

b

c

d

e

f

244

°

240

°

4

°

64

°

6

°

58

°

SEM713A

PBIC0187E
