GW-14

< ON-VEHICLE REPAIR >

SIDE WINDOW GLASS

WARNING:

Always wear safety glasses and heavy gloves to prevent injury.

CAUTION:

• Be careful not to scratch the glass when removing.
• Never set or stand the glass on its edge. Small chips may develop into cracks.

INSTALLATION

• Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions provided

with it.

• Open a door window while the urethane adhesive is curing. This prevents the glass from being forced out by

passenger room air pressure when all door windows are closed.

• The molding must be installed securely so that it is in position and leaves no clearance.
• Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely

cured (approximately 24 hours). Curing time varies with temperature and humidity.

WARNING:

• Keep heat and open flames away as primers and adhesive are flammable.
• The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never let

them come in contact with skin or eyes.

• Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled.

Move immediately to an area with fresh air if affected by vapor inhalation.

• Driving the vehicle before the urethane adhesive has completely cured may affect the performance

of the side window in case of an accident.

CAUTION:

• Never use an adhesive which is past its usable term. Shelf life of this product is limited to six months

after the date of manufacture. Carefully adhere to the expiration or manufacture date printed on the
box.

• Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
• Never leave primers or adhesive cartridge unattended with their caps open or off.
• Never drive the vehicle within 24 hours or until the urethane adhesive has completely cured. Curing

time varies depending on temperature and humidity. The curing time will increase under lower tem-
perature and lower humidity.

Inspection

INFOID:0000000003825402

Repairing Water Leakage for side window glass

Leakage can be repaired without removing glass.
Determine the extent of leakage if water is leaking between the urethane adhesive material and body or glass.
This can be done by applying water to the side window glass area while pushing glass outward.
Apply primer (if necessary) and then urethane adhesive to the leakage point to stop the leakage.

REAR WINDOW GLASS

GW-15

< ON-VEHICLE REPAIR >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

REAR WINDOW GLASS

Exploded View

INFOID:0000000003825403

Removal and Installation

INFOID:0000000003825404

REMOVAL

1.

Remove rear seatback and rear seat cushion. Refer to

SE-99, "Removal and Installation"

.

2.

Remove rear pillar finisher (RH/LH). Refer to

INT-39, "Removal and Installation"

.

1.

Rear window glass

2.

Dam sealant rubber

3.

Spacer

4.

Roof

5.

Primer

6.

Adhesive

7.

Body side outer

8.

Parcel shelf

9.

Headlining assembly

10.

Rear pillar finisher

11.

Trunk lid outer

12. Rear parcel shelf finisher

Unit

: mm (in)

Refer to

GI-4, "Components"

 for symbols in the figure.

JMKIA2307GB

GW-16

< ON-VEHICLE REPAIR >

REAR WINDOW GLASS

3.

Remove rear parcel shelf finisher. Refer to

INT-43, "Removal and Installation"

.

4.

Remove partially the headlining assembly (rear edge). Refer to

INT-50, "NORMAL ROOF : Removal and

Installation"

for normal roof and to

INT-54, "SUNROOF : Removal and Installation"

 for sunroof.

5.

Remove connectors and ground from the rear window defogger.

6.

Remove glass using piano wire or power cutting tool (A) and an inflatable pump bag (B) after removing
molding using pliers.

• NOTE:

Mark the body and the glass with matching marks if the rear window glass is reused.

WARNING:

Always wear safety glasses and heavy gloves to prevent injury.

CAUTION:

• Never use a cutting knife or power cutting tool when the rear window glass is reused.
• Be careful not to scratch the glass when removing.
• Never set or stand the glass on its edge. Small chips may develop into cracks.

INSTALLATION

• The dam sealant rubber should be installed in position.
• Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the instructions provided

with it.

• Open a door window while the urethane adhesive is curing. This prevents the glass from being forced out by

passenger compartment air pressure when all door windows are closed.

• Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely

cured (approximately 24 hours). Curing time varies with temperature and humidity.

WARNING:

• Keep heat and open flames away as primers and adhesive are flammable.
• The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Never

let them come in contact with skin or eyes.

• Use in an open, well ventilated location. Never breathe the vapors. They may be harmful if inhaled.

Move immediately to an area with fresh air if affected by vapor inhalation.

• Driving the vehicle before the urethane adhesive has completely cured may affect the performance

of the rear window in case of an accident.

CAUTION:

• Never use an adhesive which is past its usable term. Shelf life of this product is limited to six

months after the date of manufacture. Carefully adhere to the expiration or manufacture date
printed on the box.

• Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
• Never leave primers or adhesive cartridge unattended with their caps open or off.
• Never drive the vehicle within 24 hours or until the urethane adhesive has completely cured. Cur-

ing time varies depending on temperature and humidity. The curing time increases under lower
temperature and lower humidity.

Inspection

INFOID:0000000003825405

REPAIRING WATER LEAKAGE FOR REAR WINDOW GLASS

Leakage can be repaired without removing the glass.
Determine the extent of leakage if water is leaking between the urethane adhesive material and body or glass.
This can be done by applying water to the back door window glass area while pushing glass outward.
Apply primer (if necessary) and then urethane adhesive to the leakage point to stop the leakage.

PIIB5779E

FRONT DOOR GLASS

GW-17

< ON-VEHICLE REPAIR >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

FRONT DOOR GLASS

Exploded View

INFOID:0000000003825379

Removal and Installation

INFOID:0000000003825380

REMOVAL

1.

Remove front door finisher. Refer to

INT-30, "DRIVER SIDE : Removal and Installation"

.

2.

Remove front door corner cover. Refer to

MIR-15, "DOOR MIRROR ASSEMBLY : Exploded View"

.

3.

Remove front door inside seal.

4.

Remove both seals (A) as shown in the figure.

1.    Front door glass run

2.

Front door glass

3.

Module base

4.

Power window motor

5.

Regulator assembly

6.

Front door inside seal

7.

Corner cover

8.

Front door panel

: Clip

: Vehicle front

JMKIA2309ZZ

JMKIA2310ZZ
